Telemecanique Sensors

Telemecanique Sensors XSDH607339H7 Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn60mm, 12...48 VDC, terminals

Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn60mm, 12...48 VDC, terminals
  • MPN: XSDH607339H7
  • PPN: TES-XSDH607339H7
  • UNSPSC: 39122230

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$437.28/ EA

Description

This XSD is a part of the OsiSense XS product range of inductive proximity sensors. Inductive proximity sensors enable the detection, without physical contact, of metal objects. Its range of applications is very extensive and includes monitoring the position of machine parts (cams, end stops, etc.) or counting the presence of metal objects. These sensors have high operating rates, fast response, and excellent resistance to industrial environments (robust products, fully encapsulated in resin). The nominal sensing range of this sensor is 2.36in (60mm). The sensor accepts 12VDC to 48VDC power and provides a normally open and normally closed discrete PNP output. The sensor is a non flush mountable plastic sensor with frontal sensing face and screw clamp terminals. It is compliant with UL, CE, CSA, and CCC standards and IP67 rated. It is suitable for railway, mobile equipment, material handling/conveying/logistics, material working/machine tools, packaging, robotics, food and beverage industries. This product is certified by CE, CCC, CSA and UL. Inductive sensors come in flush and non-flush versions, M8, M12, M18, M30 short and long bodies cylindrical forms, standard cubic, rectangular and flat forms. The inductive proximity sensors for non contact sensing of metal objects up to 60mm. It is designed for use in industrial applications relating to presence detection.

Specifications

Environment

Product Certifications
CCC || UL || CSA
Ambient Air Temperature For Operation-25-70 °C

Contractual warranty

Warranty
18 months

Offer Sustainability

Rohs Exemption Information
Yes
Environmental Disclosure
ENVPEP071001EN
Eu Rohs Directive
Pro-active compliance (Product out of EU RoHS legal scope)
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Reach RegulationReference contains Substances of Very High Concern above the threshold

Complementary

Height
100 mm
Switching Capacity In Ma
<= 200 mA
Detection Face
frontal
Width
80 mm
Depth
40 mm
Material
plastic
Detector Flush Mounting Acceptancenon flush mountable
Cable Entry1 entry tapped for 1/2" NPT cable gland
MarkingCE
Front Materialplastic
Output Circuit TypeDC
Switching Frequency<= 50 Hz

Specifications

Series Name
general purpose
[Us] Rated Supply Voltage
12...48 V DC
Discrete Output Function
1 NO + 1 NC
Range Of Product
Telemecanique Inductive proximity sensors XS
[Sn] Nominal Sensing Distance
60 mm
Sensor Design
form 80 x 80 x 40
Sensor Name
XSD
Wiring Technique
4-wire
Electrical Connectionscrew-clamp terminals
Discrete Output TypePNP
Type Of Output Signaldiscrete
Body Typefixed
Sensor Typeinductive proximity sensor
Enclosure Materialplastic
Size40 mm
Ip Degree Of ProtectionIP67
