Schneider Electric ZBVB57 Harmony XB4 & XB5 Light Block, 24V, IP20, Orange, Integral LED
- MPN: ZBVB57
- PPN: SCH-ZBVB57
CAD
$54.68
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
This Harmony ZB, orange light block operates with an integral LED. It is supplied with 24V AC/DC. It is compatible with Harmony XB4 and XB5. This light block allows fast and easy replacement and configuration of your signaling units. It is easily installed and replaced on compatible illuminated push-button or selector switch units via clip together assembly and connected with simple screw-clamp connections. It enables visual distinction of signaling units via illumination by integral LED. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
Documentation & Downloads
Specifications
Key Specifications
- Connections - Terminals
- pins for printed circuit board
- Range Of Product
- Harmony XB5 || Harmony XB4
- Light Source Colour
- orange
- Light Block Supply
- direct
- Device Short Name
- ZBV
- Bulb Base
- integral LED
Sale Per Indivisible Quantity5
Signalling Typesteady
Light Sourceprotected LED
Product Or Component Typelight block
[Us] Rated Supply Voltage24 V AC/DC 50/60 Hz
Complementary
- Mounting Of Block
- front mounting
- Surge Withstand
- 1 kV IEC 61000-4-5
- Electrical Composition Code
- M1 || M2 || M3 || M4 || M5 || M6 || M10 || MF1 || P1 || P2 || PF1
- Current Consumption
- 18 mA
Service Life100000 h at rated voltage and 25 °C
Supply Voltage Limits19.2-30 V DC || 21.6-26.4 V AC
Net Weight0.004 kg
Environment
- [Us] Rated Supply Voltage
- 24 V
- Resistance To Electromagnetic Fields
- 10 V/m IEC 61000-4-3
- Standards
- CSA C22.2 No 14 || EN/IEC 60947-5-5 || JIS C8201-5-1 || EN/IEC 60947-5-1 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || UL 508 || JIS C8201-1
- Protective Treatment
- TH
- Ip Degree Of Protection
- IP20 IEC 60529
Ambient Air Temperature For Operation-40-70 °C
Ambient Air Temperature For Storage-40-70 °C
Resistance To Electrostatic Discharge6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2
Resistance To Fast Transients2 kV IEC 61000-4-4
Electromagnetic Emissionclass B IEC 55011
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- China Rohs Regulation
- X
- Rohs Exemption Information
- Yes
- Sustainable Offer Status
- Green Premium product
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Circularity ProfileENVEOLI2302007EN
Environmental DisclosureENVPEP2302007EN
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
