Telemecanique Sensors 9007CT62 Limit switch base, 9007, receptacle c +options
- MPN: 9007CT62
- UPC: 785901500896
- PPN: TES-9007CT62
- UNSPSC: 39122213
CAD
$35.60
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Limit switch base, 9007, receptacle c +options
Documentation & Downloads
Specifications
Key Specifications
- Series Name
- heavy duty
- Body Type
- standard plug-in
- Environmental Characteristic
- standard environment
- Ambient Air Temperature For Operation
- -20-185 °F standard environment
- Product Or Component Type
- limit switch base
- Device Short Name
- 9007C
Sale Per Indivisible Quantity1
Range Of Product9007
Electrical Connectionscrew-clamp terminals AWG 22...AWG 12), 1-2
Cable Entry1 entry for 1/2" - 14 NPT ANSI B1.20.1
Product Compatibility9007C
Complementary
- Height
- 3.14-3.14 in
- Associated Head
- 9007C
- Width
- 1.55 in
- Depth
- 0.9 in
Mechanical Durability10000000 cycles
Body Materialzinc
Associated Connection Component9007CO62 || 9007CO66 || 9007CO68
Net Weight0.48 kg
Environment
- Ambient Air Temperature For Storage
- -20-185 °F
- Electrical Shock Protection Class
- class 0 IEC 61140
- Vibration Resistance
- 25 gn 10-150 Hz)IEC 60068-2-6
- Ip Degree Of Protection
- IP67 IEC 60529
Nema Degree Of ProtectionNEMA 1 Nema type 250 || NEMA 2 Nema type 250 || NEMA 4 Nema type 250 || NEMA 6 Nema type 250 || NEMA 6P Nema type 250 || NEMA 12 Nema type 250 || NEMA 13 Nema type 250
Shock Resistance60 gn 9 ms IEC 60068-2-27
Protective Treatmentepoxy powder coat
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Environmental Disclosure
- ENVPEP111160EN
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Eu Rohs DirectiveNot applicable, out of EU RoHS legal scope
