Hubbell Wiring Device-Kellems HBL2465 Industrial Twist-Lock Flanged Inlet 20A 3-Phase WYE 347/600V AC 4-Pole 4-Wire
- MPN: HBL2465
- UPC: 783585038452
- PPN: HBL-HBL2465
- UNSPSC: 39121406
CAD
$94.31
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Locking Devices, Twist-Lock®, Industrial, Insulgrip® Flanged Inlet, 20A 3-Phase Wye 347/600V AC, 4-Pole 4-Wire Non-Grounding, NEMA L20-20P, Screw Terminal, Nylon casing, Back wired, White
Features
- Backwired terminations for ease of installation
- #10-32 Multiple drive terminal screws (Slotted, Phillips, Robertson)
- Mounting screws included
- Standard Product
Specifications
Additional
- Amperage
- 20 A
- Poles
- 4-Pole
- Dielectric Voltage
- 2000 V minimum
- Current Interrupting
- Certified for current interrupting at full rated current
- Connectivity
- Back Wired Screw Terminals
- Length
- 3.06 in
- Height
- 2.27 in
- Material
- Nylon
- Blades Material
- Brass
- Assembly Screws Material
- Steel, nickel plated
- Wire Size
- #16 AWG to #8 AWG solid or stranded copper wire
- Moisture Resistance
- IP20
- NEMA Rating
- L20-20P
- Country of Origin
- PR
Voltage347/600 V AC, 3 Phase WYE
Wires4-Wire
Operating Temperature Range-40°C to 75°C
Device TypeFlanged Inlet, Twist-Lock
Dimensions3.06 in x 3.06 in x 2.27 in
Width3.06 in
Weight0.3 lb.
Terminal Screws Material#10-32 Brass (Slotted, Phillips, Robertson)
Terminal Clamp MaterialCold rolled steel, nickel plated
Mounting Screw MaterialNickel plated brass
FlammabilityUL94/CSA 22.2 No.0.17 HB or better
StandardsUL 498, CSA C22.2 No.42, Fed.Spec. W-C-596
ColorWhite
