Square D QOU330 Miniature Circuit Breaker 30A 3 Pole 240VAC 10kA 2.25 Inch Width

MPN: QOU330
UPC: 785901418924
PPN: SCH-QOU330

Spec sheet

In Stock

Company Stock:

Lead times may vary. For an accurate estimate please contact us.

Loading dialog...

Looking to buy a large quantity?

To view product inventory

CAD$912.12/ EA

Qty:

Loading add to cart quantity...

Description

QO™ and QOU Miniature Circuit Breakers, QOU330, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit.

Specifications

Circuit Breaker Type: standard

Voltage: 120/240 V AC, 48 V DC

Poles: 3

Width: 2.25 in

Depth: 2.95 in

Awg Gauge: AWG 14...AWG 2 aluminum/copper

Electrical Connection: slotted box lugs, line side and load side

Mercury Free: Yes

Toxic Heavy Metal Free: Yes

Product Certifications: CSA, UL Listed, IEC

Warranty: 18 months

Current Rating30 A

Interrupt Rating10 kA

Range Of ProductQOU

Height4.05 in

Tightening Torque45 lbf.in

Mounting Modeunit mount

MaterialNot specified

Halogen Content PerformanceHalogen free

RoHS ComplianceCompliant with Exemptions

Country of OriginMexico
