Square D QOU330VH QO Mini Circuit Breaker, 35A, 3 Pole, 240V AC, 22kA Rating
- MPN: QOU330VH
- UPC: 785901560067
- PPN: SCH-QOU330VH
CAD
$1041.85
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
QO™ and QOU Miniature Circuit Breakers, QOU330VH, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit.QOU breakers are able to operate up to 22 kA short ciruit current. .
Documentation & Downloads
Specifications
Additional
- Voltage
- 120/240 V AC
- Short Circuit Current Rating
- 22 kA
- Mounting Mode
- unit mount
- Width
- 2.25 in
- Tightening Torque
- 45 lbf.in
- Material
- aluminum/copper, AWG 14...AWG 2
- Circuit Breaker Application
- HACR rated
- Halogen Content Performance
- Halogen free product
- RoHS Exemption Information
- Yes
- Reach Regulation
- Contains SVHC above threshold
- Mercury Free
- Yes
- Range Of Product
- QOU
- Warranty
- 18 months
Amperage30 A
Poles3
Height4.05 in
Depth2.95 in
Electrical Connectionslotted box lugs, line side and load side
Circuit Breaker Typestandard
Product CertificationsIEC, UL listed, CSA
Toxic Heavy Metal FreeYes
China RoHS RegulationOut of China RoHS scope
EU RoHS DirectiveCompliant with exemptions
Product Or Component Typeminiature circuit-breaker
Country of OriginMexico
