Mersen MPDB900071 Large Power Distribution Block 1000V 1520A 1-Pole 4 #4 In-Out
Mersen MPDB900071 Large Power Distribution Block 1000V 1520A 1-Pole 4 #4 In-Out
- MPN: MPDB900071
- UPC: 782001456245
- PPN: FER-MPDB900071
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$587.39/ EA
Description
The Next Generation Power Distribution Block (PDB). Mersen power distribution blocks provide a safe and easy method of splicing cables, splitting primary power into secondary circuits and fulfilling requirements for fixed junction tap-off points. All blocks are UL and CSA approved while meeting spacing requirements for feeder and branch circuits in conjunction with UL508A and the National Electrical Code®. PDB options include single or dual conductor primary inputs and up to 30 secondary outputs. Specialty blocks are available allowing for up to 7 primary inputs. The MPDB series is offered in three size categories: miniature (MPDB62 and MPDB63 series), intermediate (MPDB66 and MPDB67 series), and large (MPDB68 and MPDB69 series), in both aluminum and copper.
Specifications
Specifications
- Rated voltage AC UL
- 1000 V
- Frequency (Hz)
- 50/60 Hz
- Ampere Rating (CU)
- 1520 A
- AC or DC
- AC/DC
- Short Circuit Rating (Class G)
- Not Tested
- Short Circuit Rating (Class L)
- Not Tested
- Short Circuit Rating (Class RK5)
- Not Tested
- Short Circuit Rating (Class T)
- Not Tested
- Connector Material
- Tin-plated Aluminum
- Number of Openings per Pole (Secondary)
- 4
- Connector Type (Secondary)
- Box
- Hex/Screw Size & Type (Secondary)
- 13/16-16 x 1.06
- Hole Diameter (Secondary)
- 0.88 in
- Torque Rating (Secondary)
- 500-#4 500
- Wire Range (Secondary)
- 500-#4
- Body/Insulating Material
- Glass Filled Polycarbonate
- Length
- 5.7 in
- Weight
- 3.7 lb
Rated voltage DC UL1000 V
Ampere Rating (AL)1240 A
ROHS CompliantYes
Short Circuit Rating (Class CC)Not Tested
Short Circuit Rating (Class J)Not Tested
Short Circuit Rating (Class RK1)Not Tested
Short Circuit Rating (Standalone)10 kA
Number of Poles1-Pole
Number of Openings per Pole (Primary)4
Connector Type (Primary)Box
Hex/Screw Size & Type (Primary)13/16-16 x 1.06
Hole Diameter (Primary)0.88 in
Torque Rating (Primary)500-#4 500
Wire Range (Primary)500-#4
Installation MountingDirect Screw Mount
Width5.31 in
Height3.55 in
