Intermatic ELC4536 NIGHTFOX Standard Grade Electronic Photocontrol, 120-277 V
- MPN: ELC4536
- UPC: 078275142961
- PPN: INT-ELC4536
- UNSPSC: 39121524
CAD
$21.05
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
LED-compatible photocontrol features a 10-year life expectancy. Ideal for single fixture control of smaller LED fixtures that require a cost-effective solution.
Features
- Non-drift silicon light sensor with IR filter.
- All components meet 10-year life expectancy.
- Exceeds 5,000 ON/OFF switching cycles.
- Ideal for single HID and LED fixtures (up to 550 W @ 277 VAC).
- Power-up ON delay (45-60 sec) for easy installation verification and troubleshooting.
- 510 J MOV surge protection.
Documentation & Downloads
Specifications
Additional
| Voltage | 120-277 VAC, 50/60 Hz |
|---|---|
| Surge Protection | 510 J MOV |
| Height | 2.75 in |
| Weight | NA lbs |
| Warranty Period | 6-Year limited |
| Certifications | UL Listed, cULus, RoHS, Title 20, ANSI C136.10 |
| Country of Origin | Mexico |
| Power Capacity | 550 W @ 277 VAC |
|---|---|
| Operating Temperature Range | -40 C to 70 C |
| Diameter | 3.375 in |
| Material | Polycarbonate with Acrylic Window |
| Applications | Outdoor Lighting Control |
| Color | Blue |
