Schneider Electric 9001KP7 Harmony 9001K Pilot Light Head, Metal, 30mm, 220-240V, Mercury Free

MPN: 9001KP7
UPC: 785901008743
PPN: SCH-9001KP7

$184.48

Available to Order

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

The Harmony 9001KP7 pilot light head from Schneider Electric combines robust design with reliable functionality, making it an essential component for automation and control systems. With a metal construction and a compact 30mm size, this pilot light is built to withstand industrial environments while offering clear visibility. Operating at 220-240V and being mercury-free, it aligns with modern safety and environmental standards, ensuring peace of mind for any installation. Ideal for control panels and machinery, this pilot light head enhances operational clarity and efficiency in any setting.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Mexico, United States

Physical Attributes

Size	30 mm

Important Information Attributes

Persona Type Ids	BM9, EU, LC, OM, OM8, PB, SC, SI, VR
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Light Block Supply	via transformer 220 V AC 50/60 Hz, via transformer 240 V AC 50/60 Hz, via integral transformer
Local Data Status	Publishable
Return Indicator	N
Stock Policy	2
Weee Product Category	5
Eoli Availability Display	Yes
Reach Full Compliance Status	Reference contains Substances of Very High Concern above the threshold
Reach Compliance Directive	Reference contains Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant By Exemption
Rohs Eur Full Compliance Status	Compliant By Exemption
China Rohs Label	7
Without Single Use Plastic	Yes
Tier Id	2
Function Option Id	STANDARD
Product Kit Identifier	N
Bulb Base	BA 9s
Light Source	incandescent bulb
Operating Mode	normal
Product Or Component Type	head for pilot light
Returnability	No
Supply Frequency	50...60 Hz
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
[Us] Rated Supply Voltage	220...240 V
Nbr. Of Units In Pkg.	1
Take-back	No
Customs Code	8531809051

Persona Type Names	Charge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
Market Segmentation	Commercial, Industrial
Certificate Agency	CE, UL listed file E42259 CCN NKCR, CSA LR25490 class 3211 03
Local Publishable Date	2026-01-12
Stocking Flag	Y
Weee Scope	In
Scope Perimeter	At least in Europe
End Of Life Doc Ref	ENVEOLI2503027EN
Reach Full Compliance Status Id	CONTAINS_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	1930
China Rohs In Scope	Yes
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	2
Function Option	Standard
Bezel Material	metal
Device Short Name	K
Mounting Diameter	30 mm
Product Availability	Stock - Normally stocked in distribution facility
Range Of Product	Harmony 9001K
Shape Of Screw Head	round
Sustainable Packaging	Yes
Pep Code	ENVPEP2503027EN
Cap/Operator Or Lens Colour	without cap
Package Weight(Lbs)	226.796 g
Warranty (In Months)	18

Environment Attributes Main

Take Back	No
China Rohs Regulation	X
Circularity Profile	ENVEOLI2503027EN
Eu Rohs Directive	Compliant By Exemption
Nema Degree Of Protection	NEMA 3R/6/13
Packaging Without Single Use Plastic	Yes
Pep Code	ENVPEP2503027EN

Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Environmental Disclosure	ENVPEP2503027EN
Ip Degree Of Protection	IP65/IP66
Packaging Made With Recycled Cardboard	Yes
Reach Regulation	Reference contains Substances of Very High Concern above the threshold
