Schneider Electric METSEPM8113 Power quality meter, PowerLogic PM8000, Essential, transducer, 64MB, 128s/c
- MPN: METSEPM8113
- PPN: SCH-METSEPM8113
CAD
$3002.78
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
The PowerLogic PM8113 comes in a DIN Rail mount form factor with LVDC control power. It is designed to help you ensure reliability and efficiency of your power-critical facilitiy. With its modular, flexible, and power ION technology, you can build custom applications for each meter. It comes with revenue grade accuracy, multiple communication ports, and a color graphical display. Certified by third party labs for Class 0.2S energy accuracy (IEC62052-11, IEC62053-24, IEC62053-22). Cybersecurity features include secure protocols (HTTPs, sFTP, Secure ION), security event logging, Syslog protocol. Ability to enable/disable communication ports and support 50 configurable user account to help manage access. With 64MB of memory to support up to 10 data logs (160 channels), 50+ user-definable alarms, waveform captures upto 128 samples/cycle, 1/2 cycle RMS logging. The storage can also be used for custom web pages, min/max logs, energy trends, and Time of Use. The ability to timestamp events to +/-1ms utilizing time synchronization. Time synch method that include PTP (IEEE1588), NTP, IRIG-B, GPS ASCII (RS485) and network time set function. 3 digital inputs and one digital output, plus the ability to add up to 4 option modules. I/O option modules include 2 relays and 6 digital inputs or 2 analog outputs and 4 analog inputs Wide control power range of 20-60 VDC. Operating environment of -25 to +70°C; Humidity rating of 5% to 95%; Altitude up to 3000 m.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Canada
Depth90.8 mm
Communications & Management Attributes
- Communication Port Protocol
- Modbus RTU 115 kbauds - 2-wire, ION 115 kbauds - 2-wire, DNP3, IEC 61850, Modbus TCP/IPEthernet Modbus TCP/IP daisy chain 10/100 Mbit/s, RSTP 801.1d 2004
- Communication Network Type
- IPv6 (internet protocol)
Communication ServiceDHCP, SNMP, SMTP e-mail notification, RSTP support, NTP time synchronization, PTP time synchronization
Communication Port SupportETHERNETscrew terminal block RS485
Complementary Attributes
- Line Rated Current
- 1 A, 10 A, 5 A
Important Information Attributes
- Cybersecurity
- robust security logs, Syslog protocol support, password protection, port hardening, enable/disable communication ports
- Device Application
- WAGES metering, power monitoring
- Information Displayed
- voltage, current, frequency, power, energy consumption, harmonic distortion
- Market Segment
- buildings large building network management: main incomerbuildings large building network management: sub feederbuildings multi-site network management: sub feederdata center large building network management: billing: sub feederhealthcare multi-site network management: sub feeder, industry network management: sub feeder, buildings large building cost management: billing: sub feeder, buildings small building network management: main incomer, buildings medium building network management: main incomer, buildings multi-site network management: main incomer, data center network management: main incomer, healthcare small building network management: main incomer, industry multi-site network management: main incomer, utility network management: sub feeder
- Network Frequency
- 60 Hz, 50 Hz
- Power Quality Analysis
- EN 50160 2010 compliance reportIEEE 519 2014 compliance report, up to the 63rd harmonic, harmonic distortion, waveform capture, voltage sag and swell detection, programmablity (logic and math functions)IEC 62586 power quality monitoring
- Web Services
- customizable home page, file upload/download via FTP, file upload/download via SFTP, web server, alarm notification by e-mail, viewing of captured waveform (FTP), viewing of captured waveform (web), HTTPS server
- Carbon Footprint Of The Distribution Phase [A4]
- 0.5737616077149312, 0.6 kg CO2 eq.
- Carbon Footprint Of The Installation Phase [A5]
- 0.45060626220352684, 0.5 kg CO2 eq.
- Carbon Footprint Of The Use Phase [B2 B3 B4 B6]
- 203 kg CO2 eq., 202.64310837690203
- Local Data Status
- Publishable
- Return Indicator
- Y
- Stock Policy
- 2
- Serviceability
- No
- Weee Product Category
- 5
- Eoli Availability Display
- Yes
- Reach Full Compliance Status
- Reference contains Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Reference contains Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant By Exemption
- Rohs Eur Full Compliance Status
- Compliant By Exemption
- China Rohs Label
- 7
- Without Single Use Plastic
- No
- Dangerous Goods Code
- LITHIUM METAL BATTERIES IN EQUIP. BUTTON CELL-BAT EXEMPT
- Device Short Name
- PM8113
- Energy Efficiency Optimized
- False
- Installation Category
- III
- Measurement Voltage
- 57-400 V AC 42...69 Hz between phase and neutral100-690 V AC 42...69 Hz between phases
- Mounting Mode
- clip-on
- Power Consumption In W
- 18 W
- Product Name
- PowerLogic PM8000
- Range
- PowerLogic
- Sampling Rate
- 128 samples/cycle
- Sustainable Packaging
- No
- Weee Label
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Database Version
- 2025-04
- Pcr Version
- PEP-PCR-ed4-2021 09 06
- Type Of Verification For The Pep
- Independent external review
- Functional-unit Description
- The functional unit of the PowerLogic PM8000 series is a high-precision power and energy meter designed for advanced monitoring and analysis. It operates with a low power consumption of 4.7 W in active mode and supports 100% runtime, with a total energy consumption of 411.72 kWh for active components for 10 years. It features robust cybersecurity with secure protocols (HTTPS, SFTP), Syslog support, and 50 configurable user accounts. With 512 MB memory, it supports 50 data logs, waveform captures, alarms, energy trends, and custom web pages. It offers precise event timestamping to ±1 ms using PTP, NTP, IRIG-B, GPS, and network time sync. The device includes 3 digital inputs, 1 digital output, and supports up to 4 I/O modules (relays, analog/digital I/Os). It operates in harsh environments (-25 to +70°C, 5–95% humidity, up to 3000 m altitude) and mounts via DIN rail with optional remote display.
- Functional-unit Unit
- unit
- Energy Consumption On Product Lifetime In Kwh
- 411.72
- Energy Model - Installation [A5]
- No energy used
- Energy Model - End Of Life [C1-c4]
- Global, European and French datasets are used.
- Height Nominal
- 90.5 mm
- [Us] Rated Supply Voltage
- 20...60 V DC +/- 10 %
- Package Weight(Lbs)
- 854 g
- Warranty (In Months)
- 18
- Customs Code
- 9028300000
Data Recordingevent logs, min/max of instantaneous values, time stamping, GPS synchronisation, alarm logs, data logs, trending/forecasting, sag and swell logs, waveform logs, sequence of event recording, harmonics logs, 10 data recorders
Electromagnetic Compatibilityelectrostatic discharge conforming to IEC 61000-4-2radiated radio-frequency electromagnetic field immunity test conforming to IEC 61000-4-3electrical fast transient/burst immunity test conforming to IEC 61000-4-4surge immunity test conforming to IEC 61000-4-5conducted RF disturbances conforming to IEC 61000-4-6magnetic field at power frequency conforming to IEC 61000-4-8voltage dips and interruptions immunity test conforming to IEC 61000-4-11immunity to impulse waves conforming to IEC 61000-4-12conducted and radiated emissions conforming to EN 55022, conducted and radiated emissions conforming to EN 55011, conducted and radiated emissions conforming to FCC part 15, conducted and radiated emissions conforming to ICES-003conducted RF disturbances (2...150 Hz) conforming to CLC/TR 50579surge withstand (2...150 Hz) conforming to IEEE C37.90.1
Isolation VoltageIII400-690 V conforming to IEC 61010-1:ed. 3, III400-690 V conforming to EN 61010-1:ed. 3III347-600 V conforming to UL 61010-1:ed. 3, III347-600 V conforming to CSA C22.2 No 61010-1:ed. 3
Measurement Accuracycurrent +/- 0.1 %, voltage +/- 0.1 %active energy +/- 0.2 %
Number Of Poles3P, 1P + N, 3P + N
Type Of Measurementapparent power per phase, rmspower factor per phase, rmscurrentvoltage total, frequency, active and reactive power total, apparent power total, power factor total, active and reactive power per phase, rms
Certificate AgencyCE, cULus, N998
Carbon Footprint Of The End-of-life Phase [C1 To C4]2 kg CO2 eq., 1.530093881154107
Carbon Footprint Of The Manufacturing Phase [A1 To A3]32 kg CO2 eq., 32.04606541588121
Other Technical Guidehttps://download.schneider-electric.com/files?p_Doc_Ref=&p_File_name=PLSED310058EN_Web.pdf, PLSED310058EN
Local Publishable Date2025-07-10
Stocking FlagY
Device TypeRelay, Control & Measurement - measuring, monitoring device
Weee ScopeIn
Scope PerimeterAt least in Europe
End Of Life Doc RefENVEOLI1406022EN
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeYes
Rohs Eur Conformity Date2345
China Rohs In ScopeYes
With Recycled CardboardNo
Product Contributes To Saved And Avoided EmissionsNo
Product Kit IdentifierN
Display TypeWithout Display
Frequency Measurement Range42-69 Hz
Measurement Current50-10000 mA
Memory Capacity64 MB
Mounting SupportDIN rail
Product AvailabilityNon-Stock - Not normally stocked in distribution facility
Product Or Component Typepower meter
ReturnabilityYes
Software Versionv6.3.2-2
Total Lifecycle Carbon Footprint237 kg CO2 eq.
Pep CodeENVPEP1406022EN
Pep Verification Date2025-11-28
Psr VersionPSR-0005-ed3.1-EN-2023 12 08
Data Sourceextrapolated product
Functional-unit Quantity1
Reference Lifetime In Y10
Energy Model - Manufacturing [A1-a3]Electricity Mix; Low voltage; 2020; Canada, CA
Energy Model - Use [B6]Electricity Mix; Low voltage; 2020; United States, US
Recyclability Potential In %12
Width Nominal90.5 mm
Nbr. Of Units In Pkg.1
Take-backNo
Use Of Renewable Primary Energy Resources Used As Raw Materials (Mj) Benefits/Loads Beyond System Boundaries [D]2.6586
Environment Attributes Main
- Ambient Air Temperature For Storage
- -40-85 °C, -40-85 °C
- Recycled Metal Content At Cr Level
- 0 %
- Carbon Footprint
- 237.2436355438558
- Circularity Profile
- ENVEOLI1406022EN
- Eu Rohs Directive
- Compliant By Exemption
- Operating Altitude
- 9842.52 ft (3000 m)
- Packaging Without Single Use Plastic
- No
- Relative Humidity
- 5-95 %
- Pep Verification Date
- 2025-11-28
- Psr Version
- PSR-0005-ed3.1-EN-2023 12 08
Take BackNo
China Rohs RegulationX
Ambient Air Temperature For Operation-25-70 °C-25-70 °C
Environmental DisclosureENVPEP1406022EN
Ip Degree Of ProtectionIP30 conforming to IEC 60529
Packaging Made With Recycled CardboardNo
Reach RegulationReference contains Substances of Very High Concern above the threshold
Pep CodeENVPEP1406022EN
Pcr VersionPEP-PCR-ed4-2021 09 06
Type Of Verification For The PepIndependent external review
General Attributes
- Product Or Component Type
- power meter
ETIM
- ETIM 8
- EC002301
ETIM 9EC002301
Output Attributes
- Number Of Outputs
- 1 pulse
Input Attributes
- Analogue Input Type
- voltage (impedance 5 MOhm)current (impedance 0.3 mOhm)
Number Of Inputs3 digital 30 V AC3 digital 60 V DC
