Square D 9001SKT35LR Harmony 9001SK Push-to-Test Pilot Light Head, 30 mm, LED Red, 24-28V
- MPN: 9001SKT35LR
- UPC: 785901447818
- PPN: SCH-9001SKT35LR
CAD
$253.55
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
This pilot light head from Schneider Electric is designed for efficient operation within control panels and automation systems. Featuring a reliable push-to-test function, the LED red light provides clear visual indication for system status, ensuring that operators remain informed of equipment conditions. With a compact 30 mm size and compatibility for 24-28V systems, it seamlessly fits into various applications, making it a valuable addition to any industrial environment focused on safety and performance.
Documentation & Downloads
Specifications
Additional
- Voltage
- 24...28 V AC/DC
- Conventional Free Air Thermal Current
- 10 A
- Rated Impulse Withstand Voltage
- 2.5 kV IEC 60947-1
- Vibration Resistance
- 7 gn 2-500 Hz IEC 60068-2-6
- Ambient Air Temperature for Storage
- -40 to 70 °C
- Operating Position
- any position
- Mounting Diameter
- 30 mm
- CAD Overall Height
- 70 mm
- Net Weight
- 0.181 kg
- Material
- plastic
- Electrical Shock Protection Class
- class II IEC 61140
- IP Degree of Protection
- IP66 IEC 60529
- Standards
- JIS C8201-5-1, IEC 60947-5-4, CSA C22.2 No 14, IEC 60947-5-1, IEC 60947-1, JIS C 852, UL 508, JIS C8201-1
- Light Source
- red LED
- Bulb Base
- BA 9s
- Sustainable Offer Status
- Green Premium product
- Country of Origin
- MX
Short-Circuit Protection10 A cartridge fuse IEC 60947-5-1
Rated Insulation Voltage250 V IEC 60947-1
Shock Resistance50 gn IEC 60068-2-27
Ambient Air Temperature for Operation-25 to 70 °C
Operating Modepush-to-test
Size30 mm
CAD Overall Width54 mm
CAD Overall Depth42 mm
Connection Typescrew clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
Bezel Materialplastic
Protective TreatmentTC
NEMA Degree of ProtectionNEMA 1, 2, 3, 3R, 4, 4X, 12, 13
Product CertificationsUL 508, NEMA
Light Source Colourred
Contact Type and Composition1 C/O
RoHS CompliancePro-active compliance, Toxic heavy metal free, Mercury free, China RoHS
