Hubbell Premise Wiring

Hubbell Premise Wiring S1CFB Round Flush Floorbox, Cast Iron, 3.50" Pour Depth, 8.08" x 8.64" Size

Round Flush Floorbox, Cast Iron, 3.50" Pour Depth, 8.08" x 8.64" Size
Round Flush Floorbox, Cast Iron, 3.50" Pour Depth, 8.08" x 8.64" Size
Round Flush Floorbox, Cast Iron, 3.50" Pour Depth, 8.08" x 8.64" Size
Round Flush Floorbox, Cast Iron, 3.50" Pour Depth, 8.08" x 8.64" Size
  • MPN: S1CFB
  • UPC: 783585371672
  • PPN: HBL-S1CFB
  • UNSPSC: 39121307

Spec sheet

Loading compare button...

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$397.05/ EA

Description

In-Floor Delivery Systems, SystemOne, Round Flush Floorboxes, Cast Iron, 3.50" Minimum Dept of Pour, Corrosion Resistant Paint

Features

  • Corrosion resistant for on-grade applications
  • Supplied with concrete cover and closure plugs
  • Convenient cubic inch capacity (cm3) markings on interior of box
  • Cast Iron Box with PVC Riser; Threaded Hubs

Specifications

Specifications

Application - For Use On
Concrete
Cover Shape
Round
Each - Width
8.900 in
Mounting Method
Cast Into Concrete
Application
For Use in Concrete Floors
Color
Gray
Knockouts
1 in and 1 1/2 in
Size
8.08 in x 8.64 in x 3 in
Standard
cULus;UL514
Width
8.64 in
Freight Class Code
06168002
Image Actual Or Representative
A
Construction
Cast
Series
Flush - S1 Series
BOX SIZE
7.300x9.100x8.900 (in)
Carton - Number of Sub Packs
1
Carton - SCC-14 Next Lower Level Sub Pack
00783585371672
Case Weight
3.562 lb.
Lowest Level UOM
Each
Pallet Height
43.800 in
Pallet Weight
1531.800 lb.
Country of OriginUS
Dimensions8.08 in x 8.64 in x 3 in
Industry Standard(s)cULus;UL514
ServiceSingle; Multi
Cable EntryFrom Top
Height3 in
Length8.08 in
Special FeaturesCast Iron Box with PVC Riser; Threaded Hubs
TypeRound Box
Description - InvoiceFLOORBOX, SYSTEM ONE, CAST IRON
Harmonization Code7326908688
MSDS FlagNo
MaterialCast Iron Box
Base Unit of MeasureEA
Carton - Gross Weight per Pack3.562 lb.
Carton - Pack DescriptionCarton
Carton - Total Units1
Each - Pack DescriptionEach
Pallet - GTIN - Package70783585371671
Pallet Length48.000 in
Pallet Width40.000 in

Certifications

EU RoHS Indicator
No

Downloads
