Schneider Electric VZ1 TeSys Vario Additional Pole 32A 690V for V1 Switch Disconnector
- MPN: VZ1
- PPN: SCH-VZ1
CAD
$27.34
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Description
TeSys Vario add-on module, main pole 32A 690V, for Vario switch-disconnectors. To be used with V1 switch bodies. A maximum of 3 additional VZ1 modules can be attached to the switch body. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Documentation & Downloads
Specifications
Key Specifications
- Network Frequency
- 50/60 Hz
- Range Compatibility
- TeSys TeSys VARIO switch disconnector
- Performance Level
- high performance
- Contacts Type And Composition
- 1 NO
- Poles Description
- 1P
- Device Short Name
- VZ
Network TypeDC || AC
Product Or Component Typeadditional pole
RangeTeSys
Suitability For Isolationyes
Product CompatibilityV1
Complementary
- [Ue] Rated Operational Voltage
- 690 V AC 50/60 Hz
- [Ith] Conventional Free Air Thermal Current
- 32 A
- Net Weight
- 0.05 kg
- Mounting Location
- left || right
- Electrical Durability
- 100000 cycles AC-21 || 30000 cycles DC-1...5
- Width
- 16 mm
- Depth
- 35 mm
Height74 mm
[Ithe] Conventional Enclosed Thermal Current25 A
[Uimp] Rated Impulse Withstand Voltage8 kV
Connections - Terminalspower circuit screw clamp terminals 6-6 mm² flexible - with cable end || power circuit screw clamp terminals 10-10 mm² solid
Mechanical Durability100000 cycles
Tightening Torquepower circuit 2.1-2.1 N.m screw clamp terminals
Environment
- Product Certifications
- CSA || UL || GL || UKCA
- Standards
- IEC 60947-3
- Protective Treatment
- TC
- Fire Resistance
- 960 °C IEC 60695-2-1
Ambient Air Temperature For Operation-20-50 °C
Ip Degree Of ProtectionIP20 IEC 60529
Mechanical Robustnessvibrations 10...150 Hz 1 gn) IEC 60068-2-6 || shocks 11 ms 30 Gn) IEC 60068-2-27
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP2211001
- Pvc Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information
- Eu Rohs Directive
- Compliant with Exemptions
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Toxic Heavy Metal FreeYes
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Circularity ProfileN/A
Halogen Content PerformanceHalogen free product
