TeSys Vario Additional Pole 63A 690V, 1 Pole, IP20, 20mm Width
Schneider Electric

Schneider Electric VZ3 TeSys Vario Additional Pole 63A 690V, 1 Pole, IP20, 20mm Width

  • MPN: VZ3
  • PPN: SCH-VZ3

CAD

$50.57

/ EA

Available to Order

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Available To Ship Immediately:0

Loading dialog...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

VZ3 is an add-on main pole module for TeSys Vario switch-disconnector from Schneider Electric. Rated 63A 690V, to be used with V3 switch bodies. A maximum of 3 additional VZ3 modules can be attached to the switch body. Available worldwide, multi-standards certified (IEC, UL, CSA, CCC, EAC). Multi standards certified (IEC, UL, CSA, CCC, EAC).

Documentation & Downloads

Specifications

Key Specifications

Country of Origin
Brazil, Czechia, France
Depth46 mm

Important Information Attributes

Persona Type Ids
EU, LC, OM, OM8, PB
Market Segmentation Id
COMMERCIAL, INDUSTRIAL
Mounting Location
left, right
Certificate Agency
CSA, GL, UL, UKCA
Carbon Footprint Of The End-of-life Phase [C1 To C4]
0.1 kg CO2 eq., 0.13483783783783782
Carbon Footprint Of The Manufacturing Phase [A1 To A3]
0.3 kg CO2 eq., 0.341402027027027
Local Data Status
Publishable
Return Indicator
Y
Stock Policy
2
Serviceability
No
Weee Scope
In
Scope Perimeter
At least in Europe
Reach Full Compliance Status
Reference contains Substances of Very High Concern above the threshold
Reach Compliance Directive
Reference contains Substances of Very High Concern above the threshold
Rohs Eur Status
Compliant By Exemption
Rohs Eur Full Compliance Status
Compliant By Exemption
With Recycled Cardboard
Yes
Product Contributes To Saved And Avoided Emissions
No
Tier
2
Function Option
Standard
Compatibility Code
main pole module
Device Short Name
VZ
Energy Efficiency Optimized
False
Mechanical Durability
30000 cycles
Network Frequency
50/60 Hz
Performance Level
high performance
Product Or Component Type
additional pole
Range
TeSys
Software Version
v5.9.4
Sustainable Packaging
No
Total Lifecycle Carbon Footprint
1 kg CO2 eq.
Pep Code
ENVPEP2211001EN
Pep Verification Date
2025-06-18
Psr Version
PSR-0005-ed2-2016 03 29
Data Source
extrapolated product
Functional-unit Quantity
1
Reference Lifetime In Y
20
Energy Model - Installation [A5]
Electricity Mix; Production mix; Low voltage; FR
Energy Model - End Of Life [C1-c4]
Electricity Mix; Production mix; Low voltage; FR
Height Nominal
83 mm
[Ith] Conventional Free Air Thermal Current
63 A
[Ue] Rated Operational Voltage
690 V AC 50/60 Hz
Connections - Terminals
power circuit screw clamp terminals 16-16 mm² flexible - with cable endpower circuit screw clamp terminals 25-25 mm² solid
Package Weight(Lbs)
84.0 g
Warranty (In Months)
18
Persona Type NamesEnd User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
Market SegmentationCommercial, Industrial
Network TypeAC, DC
Carbon Footprint Of The Distribution Phase [A4]0.007846013513513512, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase [A5]0.02661486486486486, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase [B2 B3 B4 B6]0.5 kg CO2 eq., 0.4993700000000001
Local Publishable Date2026-06-27
Stocking FlagN
Device TypeLV equipment - LV fuse - switch
TraceabilityNo
Weee Product Category5
Eoli Availability DisplayNo need of specific recycling operations
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeYes
Rohs Eur Conformity Date1936
China Rohs In ScopeNo
Without Single Use PlasticYes
Tier Id2
Function Option IdSTANDARD
Product Kit IdentifierN
Contacts Type And Composition1 NO
Electrical Durability100000 cycles AC-2130000 cycles DC-1...5
Fire Resistance960 °C IEC 60695-2-1
Mechanical Robustnessvibrations 10...150 Hz 1 gn) IEC 60068-2-6shocks 11 ms 30 Gn) IEC 60068-2-27
Number Of Poles1P
Product AvailabilityStock - Normally stocked in distribution facility
Protective TreatmentTC
ReturnabilityYes
Suitability For Isolationyes
Tightening Torquepower circuit 4-4 N.m screw clamp terminals
Weee LabelThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Database Version2022-01
Pcr VersionPEP-PCR-ed4-2021 09 06
Type Of Verification For The PepIndependent internal review
Functional-unit DescriptionTurn off all or part of an installation by separating the installation or part of the installation of all electrical energy or earth, for safety reasons with a rated voltage 690V and rated current 12A ensuring isolation characterized by rated voltage 8KV. This function is provided for 20 years.
Functional-unit Unitunit
Energy Model - Manufacturing [A1-a3]Electricity Mix; Production mix; Low voltage; CZ
Energy Model - Use [B6]Electricity Mix; Production mix; Low voltage; FR
Recyclability Potential In %35
Width Nominal20 mm
[Ithe] Conventional Enclosed Thermal Current50 A
[Uimp] Rated Impulse Withstand Voltage8 kV
Nbr. Of Units In Pkg.1
Take-backNo
Customs Code8538908160

Environment Attributes Main

China Rohs Regulation
Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
Take Back
No
Mercury Free
Yes
Environmental Disclosure
ENVPEP2211001EN
Ip Degree Of Protection
IP20 conforming to IEC 60529
Packaging Without Single Use Plastic
Yes
Reach Regulation
Reference contains Substances of Very High Concern above the threshold
Pep Verification Date
2025-06-18
Psr Version
PSR-0005-ed2-2016 03 29
Ambient Air Temperature For Operation-20-50 °C, -20-50 °C
Recycled Metal Content At Cr Level0 %
Carbon Footprint1.0100707432432432
Eu Rohs DirectiveCompliant By Exemption
Packaging Made With Recycled CardboardYes
Product CompatibilityV3
Pep CodeENVPEP2211001EN
Pcr VersionPEP-PCR-ed4-2021 09 06
Type Of Verification For The PepIndependent internal review

General Attributes

Product Or Component Type
additional pole

ETIM

ETIM 8
EC000041
ETIM 9EC000041

Contractual Warranty Attributes

Warranty Period
18 months
Warranty18 months
