Tripp Lite U444-000-DP4K6B USB-C to DisplayPort Vertical Adapter, 3840 x 2160 (4K) Support, Black
- MPN: U444-000-DP4K6B
- UPC: 037332238092
- PPN: TRP-U444-000-DP4K6B
CAD
$15.25
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
USB-C to DisplayPort Vertical Adapter, 3840 x 2160 (4K) Support, Black
Features
- Vertical USB-C plug orientation prevents adjacent ports from being blocked
- Converts video signals from sources supporting USB-C DisplayPort Alt Mode
- Delivers UHD picture quality at resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz
- Reversible USB-C plug connects in either direction for immediate no-fuss use
- Plug-and-play operation with no software required for easy, immediate installation
- 3-year limited warranty
- USB-C to DisplayPort Adapter Connects to Your Laptop’s USB-C or Thunderbolt 3 Port
- Supports USB-C DisplayPort Alternate Mode for Converting Audio/Video Signals
- Supports Crystal-Clear 4K Video with Multi-Channel Audio and 4:4:4 Color
- Vertical Molding Prevents Blockage of Adjacent Ports
- Ready to Use Right from the Package, So You Can Plug and Play Immediately
Specifications
Features & Specifications
| Max Supported Video Resolution | 3840 x 2160 (4K x 2K) @ 60 Hz |
|---|---|
| HDCP Specification | 2.2 |
| Audio Specification | Supports 7.1-channel surround sound |
| USB Power Delivery (PD) Charging Support | No |
| Chroma Sub Sampling | 4:4:4 |
| Displayport Specification | 1.2 |
|---|---|
| USB Specification | USB 3.0 (up to 5 Gbps); USB 3.1 Gen 1 (up to 5 Gbps) |
| Driver Required | No |
| Technology | DisplayPort; USB 3.1 (Gen 1) |
Certifications
| Certifications | Certified to RoHS, REACH, CE, FCC |
|---|
Connections
| Side A - Connector 1 | USB C (MALE) |
|---|---|
| Contact Plating | Gold |
| Side B - Connector 1 | DISPLAYPORT (FEMALE) |
|---|
Physical
| Color | Black |
|---|---|
| Unit Dimensions (hwd / in.) | 0.56 x 0.82 x 2.26 |
| Unit Weight (lbs.) | 0.0192 |
| Material of Construction | ABS, PBT |
|---|---|
| Unit Packaging Type | Polybag |
User Interface, Alerts & Controls
| LED Indicators | N/A |
|---|
Input
| Bus Powered | Yes |
|---|
Environmental
| Operating Temperature Range | 32 ~ 104F (0 ~ 40C) |
|---|---|
| Relative Humidity | 0 ~ 85% RH, Non-Condensing |
| Storage Temperature Range | 5 ~ 122F (-15 ~ 50C) |
|---|
Overview
| UPC Code | 037332238092 |
|---|
Special Features
| HDR Support | Yes |
|---|
Warranty
| Product Warranty Period (Worldwide) | 3-year limited warranty |
|---|
