Tripp Lite

Tripp Lite B118-002-UHD-2 2-Port HDMI Splitter - HDMI 2.0, HDCP 2.2, 4K @ 60 Hz, HDR, TAA

2-Port HDMI Splitter - HDMI 2.0, HDCP 2.2, 4K @ 60 Hz, HDR, TAA
2-Port HDMI Splitter - HDMI 2.0, HDCP 2.2, 4K @ 60 Hz, HDR, TAA
2-Port HDMI Splitter - HDMI 2.0, HDCP 2.2, 4K @ 60 Hz, HDR, TAA
2-Port HDMI Splitter - HDMI 2.0, HDCP 2.2, 4K @ 60 Hz, HDR, TAA
  • MPN: B118-002-UHD-2
  • UPC: 037332200648
  • PPN: TRP-B118-002-UHD-2

Spec sheet

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$190.75/ EA

Description

Transmits Ultra High Definition (UHD) 4K x 2K audio/video (A/V) from an HDMI source to two HDMI displays at the same time. Recommended for digital signage in classrooms, churches, office buildings, restaurants/bars, etc.

Features

  • Transmits UHD video resolutions up to 4K x 2K @ 60 Hz
  • Distributes A/V up to 15 ft. when used with 28 AWG HDMI cable
  • Supports DTS-HD, Dolby® TrueHD and Dolby Digital Plus™
  • Compatible with HDCP 2.2, 3D, EDID and HDMI 2.0
  • Supports High Dynamic Range (HDR) for richer contrast and expanded color accuracy
  • Expand the number of connected displays, up to 32, by cascading up to 3 levels of splitters together
  • Plug and play—no software or drivers required
  • 3-year limited warranty
  • Transmits a 4K HDMI A/V Signal to 2 HDMI Displays Simultaneously
  • Supports the Most Up-To-Date Features and Formats
  • Easy to Use Almost Anywhere
  • TAA-Compliant

Specifications

Features & Specifications

Max Supported Video Resolution
3840 x 2160 @ 60Hz
HDCP Specification
2.2
Driver Required
No
EDID Compatible
Yes
Technology
HDMI
HDMI Specification2.0
Audio SpecificationDTS-HD, Dolby TrueHD, Dolby Digial Plus, and LPCM 7.1 Channel Surround Sound
Max Supported Color Depth36-bit Deep Color
3D Video SupportedYes

Certifications

Certifications
Tested to FCC, CE, ROHS

Connections

Ports
2
Side B - Connector 1
(2) HDMI (FEMALE)
Side A - Connector 1HDMI (FEMALE)
Connector PlatingNickel

Physical

Color
Black
Rackmountable
Yes
Shipping Weight (lbs.)
0.99
Material of ConstructionMetal
Shipping Dimensions (hwd / in.)2.17 x 7.24 x 6.46

User Interface, Alerts & Controls

LED Indicators
(x1) Green (Power), (x2) Orange (Signal)

Input

External Power Supply Input Specs (V / Hz / A)
100-240V, 50/60HZ, 0.35A
External Power Supply Cord Length (ft.)
4.0
External Power Supply Plug(s)
NEMA 5-15P North America; CEE 7/16 Schuko; BS 1363 UK; AS/NZS 3112 Australia
Bus Powered
No
External Power Supply Output Specs (V / A)5V, 2A
External Power Supply Cord Length (m.)1.2
External Power Supply CertificationsCE; FCC; UL; cUL; TUV; CCC; PSE; C-Tick; GS; RoHS

Environmental

Operating Temperature Range
32 to 104 F (0 to 40 C)
Relative Humidity
0% to 85% RH, Non-Condensing
Storage Temperature Range5 to 122 F (-15 to 50 C)

Overview

UPC Code
037332200648

Special Features

HDR Support
Yes

Warranty

Product Warranty Period (Worldwide)
3-year limited warranty
