Tripp Lite B118-002-HDR 2-Port HDMI Splitter 4K @ 60 Hz, HDR, HDCP 2.2, Metal Construction
- MPN: B118-002-HDR
- UPC: 037332237972
- PPN: TRP-B118-002-HDR
CAD
$176.48
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
2-Port HDMI Splitter 4K @ 60 Hz, HDR, HDCP 2.2, Metal Construction
Features
- Transmits up to 15 ft. for digital signage in bars, offices, classrooms, trade shows, etc.
- Supports UHD resolutions up to 4096 x 2160 (@ 60 Hz) for crystal-clear 4K x 2K video
- Supports multi-resolution output to allow for combination of different display types
- Supports High Dynamic Range (HDR) for richer contrast and expanded color accuracy
- Capable of cascading up to 64 total displays in sophisticated applications
- Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
- 3-year limited warranty
- HDMI Splitter Transmits 4K Video + Audio to 2 HDMI Displays at the Same Time
- Supports UHD 4K x 2K Signals up to 15 ft. via HDMI Cabling
- Multi-Resolution Support Allows Mixing and Matching of Displays of Different Resolutions
- Supports Up-To-Date Features and Formats
- Ready to Use Right Out of the Package
- TAA-Compliant for GSA Schedule Purchases
Documentation & Downloads
Specifications
Additional
- Max Supported Video Resolution
- 4096 x 2160 @ 60 Hz
- HDMI Specification
- 2.0
- Audio Specification
- DTS-HD, Dolby TrueHD, Dolby Digital Plus, LPCM 7.1 Channel Surround Sound
- 3D Video Supported
- Yes
- Ports
- 2
- External Power Supply Input
- 100-240V, 50/60 Hz, 0.35A
- External Power Supply DC Barrel Connector Specs
- OD: 5.5 x 2.1 x 7.5 mm, Positive Pin, Negative Sleeve
- Material
- Metal
- Operating Temperature Range
- 32 to 104 F (0 to 40 C)
- Relative Humidity
- 0% to 85% RH, Non-Condensing
- Unit Dimensions (H x W x D)
- 1.06 x 4.53 x 2.46 in (2.69 x 11.51 x 6.24 cm)
- Certifications
- CE, FCC, RoHS, REACH, TAA
- LED Indicators
- (1) Green (Power), (2) Orange (Signal)
- EDID Compatible
- Yes
- UPC Code
- 037332237972
Max Supported Color Depth36-bit Deep Color
HDCP Specification2.2
HDR SupportYes
Max Number of Ports (Chain)32
Voltage Compatibility (VAC)100, 110, 120, 125, 200, 208, 220, 230, 240
External Power Supply Output5V, 2A
Max Distance (Between Units)10 ft
Connector PlatingNickel
Storage Temperature Range5 to 122 F (-15 to 50 C)
RackmountableYes
Unit Weight0.49 lbs (0.22 kg)
External Power Supply CertificationsCE, FCC, UL, cUL, TUV, CCC, PSE, C-Tick, GS, RoHS
Driver RequiredNo
ColorBlack
BrandUnknown
