Tripp Lite B116-004A 4-Port DVI Splitter with Audio and Signal Booster - Single-Link DVI-I, 1920 x 1200 (1080p) @ 60 Hz, TAA
Tripp Lite B116-004A 4-Port DVI Splitter with Audio and Signal Booster - Single-Link DVI-I, 1920 x 1200 (1080p) @ 60 Hz, TAA
- MPN: B116-004A
- UPC: 037332156754
- PPN: TRP-B116-004A
Spec sheet
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$187.30/ EA
Description
4-Port DVI Splitter with Audio and Signal Booster - Single-Link DVI-I, 1920 x 1200 (1080p) @ 60 Hz, TAA
Features
- Transmits up to 81 ft. for digital signage in bars, offices, classrooms, trade shows, etc.
- Capable of cascading up to 64 total displays in sophisticated applications
- Supports HD resolutions up to 1920 x 1200 (@ 60 Hz) for crystal-clear 1080p video
- Easy plug-and-play operation for immediate connection right from the box
- Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
- 3-year limited warranty
- DVI Splitter Transmits HD Video + Audio to 4 DVI Displays at the Same Time
- Maintains 1920 x 1200 Video Resolutions with Rich Stereo Sound
- Supports High-Definition Video Signals up to 81 ft.
- Ready to Use Right Out of the Package
- TAA-Compliant for GSA Schedule Purchases
Specifications
Features & Specifications
- Technology
- DVI; Stereo Audio
Connections
- Ports
- 4
- Side A - Connector 2
- 3.5MM (FEMALE)
- Side B - Connector 2
- (4) 3.5MM (FEMALE)
Side A - Connector 1DVI-I (FEMALE)
Side B - Connector 1(4) DVI-I (FEMALE)
Physical
- Color
- Black
- Shipping Weight (lbs.)
- 1.70
- Unit Weight (lbs.)
- 1.2
Shipping Dimensions (hwd / in.)2.00 x 4.40 x 12.20
Unit Dimensions (hwd / in.)1.7 x 7.9 x 3.2
Communications
- Max 1024 x 768 Range (ft)
- 80
- Max 1440 x 900 Range (ft)
- 80
- Max 1080P Range (ft)
- 65
- Max 640 x 480 Range (ft)
- 80
- Max 1600 x 1200 Range (ft)
- 80
- Max 720P Range (ft)
- 80
Max 480P Range (ft)80
Max 1080i Range (ft)65
Max 480i Range (ft)80
Max 800 x 600 Range (ft)80
Max 1920 x 1200 Range (ft)65
Environmental
- Operating Temperature Range
- 32º to 104º F (0° to 40°C)
- Operating Humidity Range
- 20 to 90%
Storage Temperature Range-4º to 140º F (-20° to 60° C)
Storage Humidity Range20 to 90%
Overview
- UPC Code
- 037332156754
Warranty
- Product Warranty Period (Worldwide)
- 3-year limited warranty
