ILSCO SPA-1000 Aluminum Splicer/Reducer, Dual Rated, Conductor Range 1000-500, Tin Plated, UL, CSA
- MPN: SPA-1000
- UPC: 783669857122
- PPN: ILC-SPA-1000
CAD
$339.21
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Aluminum Splicer/Reducer, Dual Rated, Conductor Range 1000-500, Tin Plated, UL, CSA
Documentation & Downloads
Specifications
Key Specifications
- Height
- 1.75 in | 44.45 mm
- Weight
- 2.184 lbs
Length8.688 in | 220.6752 mm
Width1.75 in | 44.45 mm
Voltage
- Voltage Rating
- 35 kV
Dimensions
- Drive Size Main
- 9/16
- Height BX (IN)
- 2.75
- Length (mm)
- 220.6752
- Weight BX (LB)
- 2.4318
- Width (mm)
- 44.45
Drive Type MainInternal Hex
Height (mm)44.45
Tang Width (mm)0.254
Width BX (IN)6
Testing Standards
- CSA File Number
- LR-29601
- Prop65 Compliance
- This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
- UL File Number
- E6207
CSA StandardC22.2 No. 65-03
UL / CULUS SpecificationUL 486A/B Listed
Additional Class Attributes
- Connection
- Mechanical
- Number of Conductors
- 2
- Number of Ports Tap
- 1
- Wire Orientation
- Parallel
Contains DE-OX®No
Number of Poles1
Number of Ports / Wireways2
Material and Finish
- Conductor Material
- Copper, Aluminum
- Material
- Aluminum
- Wire Binding Hardware Material
- Aluminum
Connector FinishTin
Wire Binding Hardware FinishTin
Conductor Ranges
- Conductor Range AL Stranded (Primary, run, main, line)
- 1000 kcmil - 500 kcmil
- Conductor Range CU Stranded (Primary, run, main, line)
- 1000 kcmil - 500 kcmil
Conductor Range AL Stranded (Secondary, tap, load)1000 kcmil - 500 kcmil
Conductor Range CU Stranded (Secondary, tap, load)1000 kcmil - 500 kcmil
Additional Technical Specifications
- Conductor Type
- Stranded
General
- Bag Quantity
- 1
- Direct Burial
- No
- NEMA Code
- S-588-1
Carton Quantity DescriptionSTD PACK QTY 1
Dual RatedYes
UPC Code78366985712
Bolt and Screw Sizes
- Number of Wire Binding Screws per Port
- 3
- Wire Binding Torque
- 600
Wire Binding Screw Size1-1/8
Color
- Color
- Silver
Environment and Temperature
- Temperature Rating
- 90°C
