APC SMT2200RM2U Smart-UPS 2200VA Line Interactive Rackmount 2U 120V Sine Wave Output, 8 Outlets
APC SMT2200RM2U Smart-UPS 2200VA Line Interactive Rackmount 2U 120V Sine Wave Output, 8 Outlets
- MPN: SMT2200RM2U
- UPC: 731304279532
- PPN: APC-SMT2200RM2U
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$3171.64/ EA
Description
Smart-UPS 2200VA Line Interactive Rackmount 2U 120V Sine Wave Output, 8 Outlets
Features
- Cold-start capable — Provides temporary battery power when the utility power is out.
- Energy meter — Provides actual kilowatt hours of usage for energy conscious users.
- Green mode — Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- High online efficiency — Reduces utility costs, generates less heat.
- Intelligent Card Slot — Customize UPS capabilities with management cards.
- Intuitive LCD interface — Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
- Predictive replace battery date — Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
- Pure sine wave output on battery — Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
- Sequenced network shutdown and reboot — Customize network shutdown and reboot sequence of connected servers and UPSs.
- Single switched outlet group — Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
- StruxureWare Data Center Expert compatible — Enables centralized management via StruxureWare Data Center Expert.
- Temperature-compensated battery charging — Prolongs battery life by regulating the charge voltage according to battery temperature.
Specifications
Conformance
- Approvals
- CSA
Equipment protection policyLifetime : $150000
Battery
- Typical recharge time
- 3
Battery TypeLead-acid battery
Sustainability
- RoHS
- Compliant
Physical
- Interface Port(s)
- RJ-45 Serial,Smart-Slot,USB
- Rack Height
- 2
- Surge Energy Rating
- 530
Product OrientationRack
ColorBlack
Mount PositionFront
Input
- Cord Length
- 8.01
- Input Connection Type
- NEMA 5-20P
Cord Length (metric)2.4 cm
Input Voltage[seVoltCodes:120]
Output
- Output Power Capacity, VA
- 1920
- Nominal Output Voltage
- 120V
- Waveform type
- Sine wave
Output Connections8
TopologyLine interactive
Height, Width, Depth
- Height
- 3.39 in
- Width
- 18.9 in
- Depth
- 26.89 in
Height (metric)8.6 cm
Width (metric)48.0 cm
Depth (metric)68.3 cm
Warranty
- Warranty
- 3 years repair or replace (excluding battery) and 2 years for battery
