ABB CA4-31E Front Mount Auxiliary Contact Block, 3NO/1NC, 50Hz/60Hz Rated
- MPN: CA4-31E
- UPC: 804325559812
- PPN: ABB-CA4-31E
CAD
$138.52
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Front Mount Auxiliary Contact Block, 3NO/1NC, 50Hz/60Hz Rated
Specifications
Additional
- Rated Frequency
- Auxiliary Circuit 50 Hz / 60 Hz
- Conventional Free-air Thermal Current
- 16 A at 40 6C
- Rated Operational Current DC-13
- (125 V) 0.55 A / 69 W, (24 V) 6 A / 144 W, (250 V) 0.27 A / 68 W, (48 V) 2.8 A / 134 W, (72 V) 1 A / 72 W, (110 V) 0.55 A / 60 W, (220 V) 0.27 A / 60 W, (400 V) 0.15 A / 60 W, (500 V) 0.13 A / 65 W, (600 V) 0.1 A / 60 W
- Rated Short-time Withstand Current
- 1.5 A for 0.1 s
- Maximum Mechanical Switching Frequency
- 3600 cycles/hour
- Number of Auxiliary Contacts NO
- 3
- Tightening Torque
- Auxiliary Circuit 11 in-lb
- Wire Stripping Length
- Auxiliary Circuit 10 mm
- Material
- Not Specified
- Product Type
- AF
- Product Net Weight
- 0.055 kg
- Buy American Act (BAA) Compliance
- Contact Manufacturer
Rated Operational VoltageAuxiliary Circuit 24 ... 690 V
Rated Operational Current AC-15(220/240 V) 4 A, (24/127 V) 6 A, (500 V) 2 A, (690 V) 2 A, (400/440 V) 3 A
Rated Insulation VoltageUL/CSA 600 V, IEC 60947-5-1 and VDE 0110 (Gr. C) 690 V
Maximum Electrical Switching FrequencyAC-15 1200 cycles/hour, DC-13 900 cycles/hour
Secondary Rated Impulse Withstand Voltage6 kV
Number of Auxiliary Contacts NC1
Connecting Capacity Auxiliary CircuitFlexible with Ferrule 1/2x 0.75 ... 2.5 mm6, Flexible with Insulated Ferrule 1x 0.75 ... 2.5/2x 0.75 ... 1.5 mm6, Rigid 1/2x 1 ... 2.5 mm6
Terminal TypeScrew Terminals
Block Contactor TypeAux Contact
Object Classification CodeK
RoHS StatusRoHS Compliant (EU Directive 2011/65/EU)
American Recovery and Reinvestment Act (ARRA) ComplianceContact Manufacturer
