Schneider Electric LA1KN04 TeSys K Auxiliary Contact Block, 4NC, IP20, Front Mounting

MPN: LA1KN04
PPN: SCH-LA1KN04
UNSPSC: 39121522

$31.43

Available to Order

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K). It provides 4NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC).

Features

The Schneider Electric LA1KN04 auxiliary contact block is engineered for seamless front-mounting integration with your existing TeSys K miniature contactors and control relays, specifically matching the LC1K, LP1K, and CA2K series (excluding LP4K, LP5K, and CA4K). This clip-on, tool-free front mounting system eliminates the need for panel modifications or extensive downtime, allowing you to quickly expand your control circuit footprint without taking up valuable DIN rail real estate.
Featuring a dedicated 4 NC (Normally Closed) contact configuration, this add-on module lets you simultaneously handle four independent interlocking or signaling loops. This layout provides the ideal logic pathways required to implement strict safety drop-outs and operational state feedback within your automated control systems.
To satisfy rigid corporate safety compliance and project acceptance criteria, this module carries comprehensive global listings including UL 60947-5-1, CSA C22.2 No 60947-5-1, CE, UKCA, and IEC 60947-5-1 certifications. It is also an eco-friendly Green Premium product, verifying compliance with RoHS and REACh requirements so you can deploy it safely on any regulated or environmentally conscious work site.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Indonesia, Singapore
Depth	35 mm

Weight	45 g

Complementary Attributes

Ui Rated Insulation Voltage	690 V IEC 60947-5-1600 V UL 60947-5-1, 600 V CSA C22.2 No 60947-5-1
Minimum Switching Current	5 mA
Ue Rated Operational Voltage	690 V AC 25...400 Hz

Irms Rated Making Capacity	110 A at <= 690 V AC conforming to IEC 60947
Minimum Switching Voltage	17 V

Important Information Attributes

Persona Type Ids	EU, LC, OM, OM8, PB, SI
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Range Of Product	TeSys K, TeSys K control relay
Connections Terminals	screw clamp terminals 2 0.75-4 mm²flexible without cable endscrew clamp terminals 2 1.5-4 mm²rigidscrew clamp terminals 1 0.34-1.5 mm²flexible with cable endscrew clamp terminals 1 0.75-4 mm²flexible without cable endscrew clamp terminals 1 1.5-4 mm²rigid, screw clamp terminals 2 0.34-1.5 mm²flexible with cable end
Certificate Agency	CB Scheme, CCC, UL, CSA, CE, UKCA
Carbon Footprint Of The End Of Life Phase C1 To C4	0.1 kg CO2 eq., 0.11352
Carbon Footprint Of The Manufacturing Phase A1 To A3	0.9 kg CO2 eq., 0.92084
Local Data Status	Publishable
Return Indicator	Y
Traceability	No
Use Carbon Footprint	3.1606
Weee Product Category	5
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	Yes
Rohs Eur Conformity Date	1926
China Rohs In Scope	No
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Associated Fuse Rating	10 A gG at <= 690 V conforming to IEC 60947
Device Short Name	LA1
Insulation Resistance	> 10 MOhm> 10 MOhm
Non Overlap Distance	0.5 mm
Product Availability	Stock - Normally stocked in distribution facility
Product Or Component Type	auxiliary contact block
Range	TeSys
Shielding Continuity Terminal	without
Sustainable Packaging	Yes
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Database Version	2022-01
Height Nominal	30 mm
Nbr. Of Units In Pkg.	1
Ith Conventional Free Air Thermal Current	10 A (at 50 °C)
Warranty In Months	18
Functional Unit Quantity	1
Reference Lifetime In Y	20

Persona Type Names	End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market Segmentation	Commercial, Industrial
Tightening Torque	1.3 N.m Philips No 2, 1.3 N.m pozidriv No 2
Connections Terminals 55 Connections Terminals	screw clamp terminals
Carbon Footprint Of The Distribution Phase A4	0.0058845, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase A5	0.0043312, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase B2 B3 B4 B6	3 kg CO2 eq., 3.1606
Local Publishable Date	2026-06-30
Serviceability	No
Field Service Division	PPIBS
Weee Scope	In
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	Yes
Tier Id	1
Function Option Id	STANDARD
Product Kit Identifier	N
Compatibility Code	LA1
Environmental Characteristic	normal environment
Mounting Location	front
Pole Contact Composition	4 NC
Product Name	TeSys K
Protective Treatment	TC IEC 60068
Returnability	Yes
Software Version	v5.9.4
Total Lifecycle Carbon Footprint	4 kg CO2 eq.
Pole Contact Comp	4 NC
Data Source	extrapolated product
Width Nominal	38 mm
Customs Code	8536509040
Permissible Short Time Rating	80 A 1 s60 A 500 ms110 A 100 ms
Functional Unit Description	To add instantaneous auxiliary contact blocks in front face on TeSys k contactors as NO and/or NC contacts for 20 years.
Functional Unit Unit	unit
Recyclability Potential In %	43

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Ambient Air Temperature For Storage	-50-80 °C, -50-80 °C
Reach Free Shvc	Yes
Toxic Heavy Metal Free	Yes
Carbon Footprint	4.205175700000001
Eu Rohs Directive	Compliant
Operating Altitude	6561.68 ft (2000 m)
Packaging Without Single Use Plastic	Yes
Reach Regulation	Free of Substances of Very High Concern above the threshold
Pep Verification Date	2025-06-17
Psr Version	PSR-0005-ed2-2016 03 29

Ambient Air Temperature For Operation	-25-50 °C, -25-50 °C
Take Back	No
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Environmental Disclosure	ENVPEP2106022EN
Ip Degree Of Protection	IP20 conforming to IEC 60529
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP2106022EN
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review
