Harmony XB5 22mm Potentiometer, 470k , IP66, Cermet
Harmony XB5 22mm Potentiometer, 470k , IP66, Cermet
Harmony XB5 22mm Potentiometer, 470k , IP66, Cermet
Schneider Electric

Schneider Electric XB5AD912R470K Harmony XB5 22mm Potentiometer, 470k , IP66, Cermet

  • MPN: XB5AD912R470K
  • PPN: SCH-XB5AD912R470K

CAD

$70.98

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

This Harmony XB5, 22mm diameter potentiometer has a resistance of 470kΩ and uses screw clamp terminals. This potentiometer provides an external interface for controlling key parameters of automation components like drives and inverters. It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 IP69 IP69K, making it ideal for operation in harsh environments. It is ideal for analog control (like speed control of motor) via the voltage or resistor input of variable speed drives. It is designed to fit in a standard 22mm cutout, ensuring compatibility when installing in pre-existing machinery.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin
Brazil, France

Physical Attributes

Cad Overall Depth
82 mm
Cad Overall Width
30 mm
Cad Overall Height42 mm
Color Of Markingwhite

Complementary Attributes

Rated Power In W
0.26 W 70 °C

Important Information Attributes

Persona Type Ids
BM9, EU, LC, OM, OM8, PB, SC, SI, VR
Market Segmentation Id
COMMERCIAL, INDUSTRIAL
Customizable
1, no
Certificate Agency
CSA, UL Listed, BV
Carbon Footprint Of The Distribution Phase [A4]
0.006276754785779399, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase [A5]
0.012486235186873291, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase [B2 B3 B4 B6]
0.5 kg CO2 eq., 0.46984
Local Publishable Date
2026-01-12
Stocking Flag
Y
Weee Scope
Out
Scope Perimeter
At least in Europe
End Of Life Doc Ref
ENVEOLI2312041EN
Reach Full Compliance Status
Free of Substances of Very High Concern above the threshold
Reach Compliance Directive
Free of Substances of Very High Concern above the threshold
Rohs Eur Status
Compliant
Rohs Eur Full Compliance Status
Compliant
China Rohs Label
1
Without Single Use Plastic
No
Tier Id
2
Function Option Id
STANDARD
Product Kit Identifier
N
Average Percentage Of Recycled Plastic Content
27 %
Compatibility Code
XB5
Electrical Shock Protection Class
class II conforming to IEC 60536
Head Type
standard
Material
cermet
Mounting Diameter
22 mm
Operator Profile
knurled knob, with white)
Product Availability
Non-Stock - Not normally stocked in distribution facility
Product Repair Index
A
Range Of Product
Harmony XB5
Returnability
Yes
Shape Of Signaling Unit Head
round
Software Version
v5.9.4
Total Lifecycle Carbon Footprint
1 kg CO2 eq.
Color Of Marking
white
Database Version
2022-01
Pcr Version
PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep
Independent internal review
Functional-unit Description
Potentiometer is used to precise control and adjustment of machines in industrial applications. Potentiometers provide a particularly easy way to control speed or configure general settings such as temperature.It is made up of metal bezel and It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. It is ideal for analog control (like speed control of motor) via the voltage or resistor input of variable speed drives.This product will be in active mode at 70% with power consumption of 0.017 W with life span of 10 years and adhering to IEC 60947-1 standards.
Energy Model - Manufacturing [A1-a3]
Electricity Mix; Production mix; Low voltage; UE-27
Energy Model - Use [B6]
Electricity Mix; Production mix; Low voltage; UE-27
Nbr. Of Units In Pkg.
1
Product Repair Index - Dam Document Id
XB4BS8442-ENVREPAIR-A-EN
Warranty (In Months)
18
Ecotoxicity (Fresh Water) (Ctue) Operational Energy Use [B6]
5.4273
Total Use Of Renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Operational Energy Use [B6]
2.0211
Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6]
2.0211
Persona Type NamesCharge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
Market SegmentationCommercial, Industrial
Precision Of Internal Conversion Resistor+-10%, +-10%
[Us] Rated Supply Voltage<= 30 V AC, <= 30 V AC, <= 42 V DC, <= 42 V DC<= 30 V AC, <= 30 V AC, <= 42 V DC, <= 42 V DC
Carbon Footprint Of The End-of-life Phase [C1 To C4]0.1 kg CO2 eq., 0.11017684594348223
Carbon Footprint Of The Manufacturing Phase [A1 To A3]0.6 kg CO2 eq., 0.5590337283500456
Local Data StatusPublishable
Return IndicatorY
Stock Policy2
Weee Product Category5
Eoli Availability DisplayYes
Product Repair Index Dam DocXB4BS8442-ENVREPAIR-A-EN
Reach Full Compliance Status IdNOT_CONTAINING_SVHC
Rohs Eur In ScopeNo
Rohs Eur Conformity Date2248
China Rohs In ScopeYes
With Recycled CardboardYes
Product Contributes To Saved And Avoided EmissionsNo
Tier2
Function OptionStandard
Average Percentage Of Recycled Metal Content16 %
Bezel Materialdark grey plastic
Device Short NameXB5
Group Of Productpotentiometer knurled knob
Main Grouppotentiometer
Mechanical Durability50000 cycles
Ohmic Value470000 Ohm
Potentiometer Characteristiclinear
Product Or Component Typepotentiometer
Protective TreatmentTH
Resistance To High Pressure Washer7000000 Pa 55 °C 0.1 m
Sale Per Indivisible Quantity1
Shock Resistance30 gn 18 ms) half sine wave acceleration IEC 60068-2-2750 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Sustainable PackagingNo
Vibration Resistance5 gn (f= 2-500 Hz) conforming to IEC 60068-2-6
Pep CodeENVPEP2312041_V1
Pep Verification Date2024-06-01
Psr VersionPSR-0005-ed2-2016 03 29
Data Sourceextrapolated product
Reference Lifetime In Y10
Energy Model - Installation [A5]Electricity Mix; Production mix; Low voltage; UE-27
Energy Model - End Of Life [C1-c4]Electricity Mix; Production mix; Low voltage; UE-27
Package Weight(Lbs)58.0 g
Take-backNo
Depletion Of Abiotic Resources - Fossil Fuels (Mj) Operational Energy Use [B6]11.033
Total Use Of Primary Energy During The Life Cycle (Mj) Operational Energy Use [B6]13.055
Use Of Non-renewable Primary Energy Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6]11.033
Customs Code8533408040

Environment Attributes Main

Ambient Air Temperature For Operation
-40-70 °C, -40-70 °C
Nema Degree Of Protection
NEMA 13, NEMA 4X, UL type 4X/13
Reach Free Shvc
Yes
China Rohs Regulation
X
Carbon Footprint
1.1578135642661804
Environmental Disclosure
ENVPEP2312041_V1
Ip Degree Of Protection
IP66 IEC 60529
Packaging Without Single Use Plastic
No
Reach Free Of Svhc
Yes
Pep Code
ENVPEP2312041_V1
Pcr Version
PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep
Independent internal review
Ambient Air Temperature For Storage-40-70 °C, -40-70 °C
Take BackNo
Recycled Metal Content At Cr Level16 %
Mercury FreeYes
Circularity ProfileENVEOLI2312041EN
Eu Rohs DirectiveCompliant
Packaging Made With Recycled CardboardYes
Product CompatibilityØ 6 mm shaft
Reach RegulationFree of Substances of Very High Concern above the threshold
Pep Verification Date2024-06-01
Psr VersionPSR-0005-ed2-2016 03 29

General Attributes

Product Or Component Type
potentiometer
Range Of ProductHarmony XB5
