ABB 1SVR405501R4020 CR-S Pluggable Relay 1 c/o, 48 V DC, 6A/250VAC, 6.2 mm Wide
ABB 1SVR405501R4020 CR-S Pluggable Relay 1 c/o, 48 V DC, 6A/250VAC, 6.2 mm Wide
- MPN: 1SVR405501R4020
- PPN: ABB-1SVR405501R4020
- UNSPSC: 39122331
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$14.20/ EA
Description
The CR-S048VDC1RG is a slim pluggable interface relay, with gold-plated output contacts, which is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. Plugged into a socket, the combination of relay and socket may be seemlessly snap-on mounted onto a DIN Rail. This relay operates with a 48 V DC rated control supply voltage and has a 1 c/o (SPDT) output with contacts rated at 250 V / 6 A.This slim pluggable interface relays may be used for electrical isolation, amplification and signal matching. Its gold-plated contacts ensure contact reliability particularly necessary in applications where small currents and loads are to be switched. The CR-S relays are 6.2 mm wide and therefore allow for the switching of high currents on a small footprint. Moreover, CR-S relays are UL 94-V0 certified, improving safety by providing high levels flame retardation. Screw and spring sockets, jumper bars and markers are available as accessories.
Specifications
Dimensions
- Product Net Width
- 5 mm
- Product Net Depth / Length
- 28 mm
Product Net Height15 mm
Product Net Weight0.005 kg
Technical
- Function
- Pluggable slim interface relay CR-S
- Rated Control Supply Voltage (Us)
- 48 V DC
- Output Signal
- 250 V / 6 A
- Rated Operational Current DC-12 (Ie)
- (24 V) 6 A
- Degree of Protection
- IP20
- Pollution Degree
- 2
Sub-FunctionRelay with gold-plated contacts
Output1 c/o (SPDT) contact
Rated Operational Current AC-12 (Ie)(230 V) 6 A
Rated Operational Current DC-13 (Ie)(24 V) 1 A
Overvoltage CategoryIII
StandardsCAN/CSA C22.2 No.14IEC/EN 61810-1UL 508
Classifications
- Object Classification Code
- K
- eClass
- V11.0 : 27371601
- E-Number (Sweden)
- 4001387
ETIM 9EC001437 - Switching relay
E-Number (Finland)2712357
Environmental
- Ambient Air Temperature
- Operation -40 ... +85 °CStorage 0 ... +40 °C
RoHS StatusFollowing EU Directive 2011/65/EU
Ordering
- Minimum Order Quantity
- 10 piece
Customs Tariff Number85364900
