Telemecanique Sensors XS7C4A1DPP20 Inductive proximity sensors XS, inductive sensor XS7 40x40x117, PBT, Sn15 mm, 12...48 VDC, terminals

MPN: XS7C4A1DPP20
PPN: TES-XS7C4A1DPP20

Spec sheet

Compare

Loading compare button...

Available to Order

Company Stock:

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$362.43/ EA

Qty:

Loading add to cart quantity...

Description

The XS range is an offer of inductive proximity sensors for the detection, without physical contact, of metal objects. The advantages of inductive detection are numerous, no physical contact with the object to be detected. Thus avoiding wear and enabling detection of fragile or freshly painted objects. High operating rates. Fast response. Excellent resistance to industrial environments (robust products, fully encapsulated in resin). This product is a 40mm x 40mm x 117mm format sensor, flush mountable in metal. It features a plastic case with a plug-in 5 position turret head and a ISO M20 cable entry. It has a sensing distance of 15mm. Two-wire, DC supply, 12V to 48V with protection against reverse polarity, NO or NC function programmable.

Specifications

Environment

Product Certifications: CCC || CSA || UL

Vibration Resistance: 25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6

Ambient Air Temperature For Storage: -40-85 °C

Ambient Air Temperature For Operation-25-70 °C

Shock Resistance50 gn 11 msEN 60068-2-27

Contractual warranty

Warranty: 18 months

Offer Sustainability

Rohs Exemption Information: Yes

Environmental Disclosure: ENVPEP121217EN

Reach Regulation: Reference contains Substances of Very High Concern above the threshold

Mercury FreeYes

Sustainable Offer StatusGreen Premium product

Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)

Complementary

Height: 40 mm

Status Led: output state 1 LED yellow)

Operating Zone: 0-12 mm

Marking: CE

Net Weight: 0.244 kg

Switching Frequency: <= 300 Hz

Maximum Delay Recovery: 1.8 ms

Supply Voltage Limits: 10-58 V DC

Detection Face: 5 positions turret head

Front Material: PBT

Maximum Delay Response1.2 ms

Repeat Accuracy<= 3% of Sr

Maximum Voltage Drop<4.2 V closed)

Length40 mm

Maximum Residual Current0.6 mA open state

Differential Travel3...15% of Sr

Maximum Delay First Up7.5 ms

Cable Entry Number1 tapped entry M20 x 1.5 cable gland

Width117 mm

Specifications

Electrical Connection: screw-clamp terminals, 4 x 1.5 mm²

Discrete Output Function: 1 NO or 1 NC programmable

Range Of Product: Telemecanique Inductive proximity sensors XS

Material: plastic

Wiring Technique: 2-wire

Series Name: general purpose

[Sn] Nominal Sensing Distance: 15 mm

Detector Flush Mounting Acceptance: flush mountable

Sensor Design: form 40 x 40 x 117

Output Circuit Type: DC

[Us] Rated Supply Voltage12...48 V DC reverse polarity protection

Type Of Output Signaldiscrete

Sensor NameXS7

Size117 mm

Ip Degree Of ProtectionIP67 IEC 60529 || IP65 IEC 60529 || IP69K DIN 40050

Body Typefixed

Sensor Typeinductive proximity sensor

Switching Capacity In Ma1.5...100 mA overload and short-circuit protection

Enclosure MaterialPBT
