Telemecanique Sensors XS7C2A1PAM12 Inductive proximity sensors XS, inductive sensor XS7 40x40x70, PBT, Sn15 mm, 12...24 VDC, M12
Telemecanique Sensors XS7C2A1PAM12 Inductive proximity sensors XS, inductive sensor XS7 40x40x70, PBT, Sn15 mm, 12...24 VDC, M12
- MPN: XS7C2A1PAM12
- PPN: TES-XS7C2A1PAM12
- UNSPSC: 39122230
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$223.68/ EA
Description
The XS range is an offer of inductive proximity sensors for the detection, without physical contact, of metal objects. The advantages of inductive detection are numerous, no physical contact with the object to be detected. Thus avoiding wear and enabling detection of fragile or freshly painted objects. High operating rates. Fast response. Excellent resistance to industrial environments (robust products, fully encapsulated in resin). This product is a 40mm x 40mm x 70mm format sensor, flush mountable in metal. It features a plastic case with a 5 position turret head and a M12 connector. It has a sensing distance of 15mm. Three-wire, DC supply, 12V to 24V, NO function, PNP discrete output .
Specifications
Environment
- Product Certifications
- CSA || E2 || CCC || UL
- Vibration Resistance
- 25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
- Ambient Air Temperature For Storage
- -40-85 °C
Ambient Air Temperature For Operation-25-70 °C
Shock Resistance50 gn 11 msEN 60068-2-27
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP121217EN
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
Complementary
- Current Consumption
- 0...15 mA no-load
- Maximum Delay Response
- 1.2 ms
- Repeat Accuracy
- <= 3% of Sr
- Maximum Voltage Drop
- <2 V closed)
- Length
- 40 mm
- Switching Frequency
- <= 300 Hz
- Maximum Delay Recovery
- 1.8 ms
- Supply Voltage Limits
- 10-36 V DC
- Width
- 70 mm
Height40 mm
Status Ledsupply on 1 LED green) || output state 1 LED yellow)
Operating Zone0-12 mm
MarkingCE
Net Weight0.149 kg
Differential Travel3...15% of Sr
Maximum Delay First Up7.5 ms
Detection Face5 positions turret head
Front MaterialPBT
Specifications
- Electrical Connection
- male connector M12, 4 pins
- Discrete Output Type
- PNP
- Type Of Output Signal
- discrete
- Sensor Name
- XS7
- Size
- 70 mm
- Ip Degree Of Protection
- IP67 IEC 60529 || IP65 IEC 60529 || IP69K DIN 40050
- Body Type
- fixed
- Sensor Type
- inductive proximity sensor
- Switching Capacity In Ma
- <= 200 mA overload and short-circuit protection
- Enclosure Material
- PBT
- Device Application
- mobile equipment
[Us] Rated Supply Voltage12...24 V DC reverse polarity protection
Discrete Output Function1 NO
Range Of ProductTelemecanique Inductive proximity sensors XS
Materialplastic
Wiring Technique3-wire
Series Namegeneral purpose
[Sn] Nominal Sensing Distance15 mm
Detector Flush Mounting Acceptanceflush mountable
Sensor Designform 40 x 40 x 70
Output Circuit TypeDC
