Schneider Electric 170ANR12091 Modicon Momentum Distributed I/O Module, 4 Discrete Outputs, 6 Analog Inputs

MPN: 170ANR12091
PPN: SCH-170ANR12091
UNSPSC: 32151601

$3561.83

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This Modicon Momentum Distributed I/O Module from Schneider Electric is an essential component for enhancing automation systems. It features four discrete outputs and six analog inputs, providing versatile connectivity options that facilitate efficient data acquisition and control in complex environments. Designed with reliability in mind, this module is versatile enough to be integrated into various applications within the automation and control sector, making it an ideal solution for streamlining processes and improving operational efficiency. With this advanced I/O module, you can ensure that your systems operate smoothly, adapting to the demands of modern industrial applications.

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Indonesia
Depth	47.5 mm

Weight	400 g

Complementary Attributes

Maximum Voltage Drop	<0.4 V 0.25 A at state on discrete output, <0.4 V 0.25 A at state on discrete output, <0.4 V 0.25 A at state on discrete output, <0.4 V 0.25 A at state on discrete output<0.4 V 0.25 A at state on discrete output, <0.4 V 0.25 A at state on discrete output, <0.4 V 0.25 A at state on discrete output, <0.4 V 0.25 A at state on discrete output
Maximum Power Dissipation In W	6 W

Maximum Leakage Current	0.4 mAdiscrete output
Us Rated Supply Voltage	24 V DC

Important Information Attributes

Persona Type Ids	EU, OM8, SI
Conversion Error	+/- 0.4 % +/- 10 V 25 °C analogue output, +/- 0.4 % +/- 10 V 25 °C analogue output, +/- 0.4 % +/- 10 V 25 °C analogue output, +/- 0.4 % +/- 10 V 25 °C analogue output, +/- 0.4 % +/- 10 V 25 °C analogue output, +/- 0.4 % +/- 10 V 25 °C analogue output, +/- 0.4 % +/- 10 V 25 °C analogue output, +/- 0.4 % +/- 10 V 25 °C analogue output
Current State 1 Guaranteed	>= 6 mA discrete input), >= 6 mA discrete input)>= 6 mA discrete input), >= 6 mA discrete input)
Group Of Channels	1 group of 8 discrete outputs, 2 groups of 4 discrete inputs, 1 group of 6 analog inputs, 1 group of 4 analog outputs
Response Time	1.2 ms from state 0 to state 1 discrete output, 1.2 ms from state 1 to state 0 discrete input1.05 ms from state 1 to state 0 discrete output, 1.2 ms from state 0 to state 1 discrete input
Voltage State 1 Guaranteed	>= 11 V, >= 11 V
Carbon Footprint Of The Distribution Phase A4	0.1194636265917277, 0.1 kg CO2 eq.
Carbon Footprint Of The Installation Phase A5	0.2 kg CO2 eq., 0.2196800274767913
Carbon Footprint Of The Use Phase B2 B3 B4 B6	141 kg CO2 eq., 141.10219037035654
Local Publishable Date	2026-01-12
Device Type	PLC System - PLC Component
Traceability	Yes
Average Life Duration	15 year(s)
Weee Product Category	5
Eoli Availability Display	Yes
Reach Full Compliance Status	Reference contains Substances of Very High Concern above the threshold
Reach Compliance Directive	Reference contains Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant By Exemption
Rohs Eur Full Compliance Status	Compliant By Exemption
China Rohs Label	5
Without Single Use Plastic	Yes
Tier Id	4
Function Option Id	ADVANCED
Market Segmentation Id	INDUSTRIAL
Product Kit Identifier	N
Bearing Track Assembly Possible	false
Current Consumption	400 mA 24 V DC
Local Signalling	8 LEDs for channel status
Network Type	DC
Product Or Component Type	analogue,discrete I/O base
Radio Standard Bluetooth	false
Radio Standard Gsm	false
Range Of Product	Modicon Momentum automation platform
Software Version	v6.2.5-6
Supporting Protocol For Can	false
Supporting Protocol For Devicenet Safety	false
Supporting Protocol For Foundation Fieldbus	false
Supporting Protocol For Knx	false
Supporting Protocol For Modbus	false
Supporting Protocol For Profibus	false
Supporting Protocol For Profinet Io	false
Supporting Protocol For Safetybus P	false
Supporting Protocol For Suconet	false
Total Lifecycle Carbon Footprint	271 kg CO2 eq.
Certified For Ul Hazardous Location Class Ii	false
Certified For Ul Hazardous Location Division 1	false
Dc Supply Voltage	24-24 V
Fieldbus Connection Over Separate Bus Coupler Possible	false
Analogue Input Signal Configurable	false
Analogue Output Signal Configurable	false
Digital Inputs Configurable	false
Time Delay At Signal Change	0.75-0.75 ms
Data Source	extrapolated product
Width Nominal	141.5 mm
Supporting Protocol For Tcp/Ip	false
Nbr. Of Units In Pkg.	1
Analogue Input Resistance Thermometer	false
Analogue Input Thermocouple	false
Appendant Operation Agent Ex Ia	false
Certified For Ul Hazardous Location Group A Acetylene	false
Certified For Ul Hazardous Location Group C Ethylene	false
Certified For Ul Hazardous Location Group E Metal Dusts	false
Certified For Ul Hazardous Location Group G Non Conductive Dust	false
Performance Level According To En Iso 13849 1	none
Radio Standard Wi Fi 802.11	false
Supporting Protocol For Data Highway	false
Warranty In Months	18
Functional Unit Quantity	1
Reference Lifetime In Y	10

Persona Type Names	End User, OEM - Control Panelbuilder, System Integrator
Current State 0 Guaranteed	<= 2 mA discrete input), <= 2 mA discrete input)<= 2 mA discrete input), <= 2 mA discrete input)
Fail State	analogue output hold, analogue output reset to zero
Isolation Voltage	500 V 1 min) between analogue I/O and operating voltage, 500 V 1 min) between operating voltage and I/O from ground
Voltage State 0 Guaranteed	<= 5 V, <= 5 V
Certificate Agency	UL, CSA
Carbon Footprint Of The End Of Life Phase C1 To C4	0.49481732134226175, 0.5 kg CO2 eq.
Carbon Footprint Of The Manufacturing Phase A1 To A3	129 kg CO2 eq., 129.1558322294498
Local Data Status	Publishable
Return Indicator	N
Serviceability	No
Field Service Division	IDIBS
Weee Scope	Out
Scope Perimeter	At least in Europe
End Of Life Doc Ref	ENVEOLI1403005EN
Reach Full Compliance Status Id	CONTAINS_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	2438
China Rohs In Scope	Yes
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	4
Function Option	Advanced
Market Segmentation	Industrial
Analogue Output Voltage2	true
Conversion Time	0.75 ms analog output1.2 ms analogue input circuit
Front Installation Possible	false
Marking	CE
Product Availability	Non-Stock - Not normally stocked in distribution facility
Protective Treatment	TC
Radio Standard Gprs	false
Radio Standard Umts	false
Returnability	No
Supporting Protocol For Asi	false
Supporting Protocol For Devicenet	false
Supporting Protocol For Ethercat	false
Supporting Protocol For Interbus	false
Supporting Protocol For Lon	false
Supporting Protocol For Other Bus Systems	false
Supporting Protocol For Profinet Cba	false
Supporting Protocol For Profisafe	false
Supporting Protocol For Sercos	false
Sustainable Packaging	Yes
Certified For Ul Hazardous Location Class I	false
Certified For Ul Hazardous Location Class Iii	false
Certified For Ul Hazardous Location Division 2	false
Digital Outputs Configurable	false
System Accessory	false
Analogue Inputs Configurable	false
Analogue Outputs Configurable	false
Short Circuit Protection Digital Outputs Available	true
Database Version	2024-01
Height Nominal	125 mm
Supporting Protocol For Ethernet/Ip	false
Wall Mounting/Direct Mounting Possible	false
Customs Code	8538908180
Analogue Input Resistor	false
Analogue Input Voltage	true
Appendant Operation Agent Ex Ib	false
Certified For Ul Hazardous Location Group B Hydrogen	false
Certified For Ul Hazardous Location Group D Propane	false
Certified For Ul Hazardous Location Group F Carbonaceous Dust	false
Io Link Master Present	false
Rack Assembly Possible	false
Supporting Protocol For As Interface Safety At Work	false
Supporting Protocol For Interbus Safety	false
Functional Unit Description	Other switchgear and controlgear solutions mentioned in the scope (e.g. fuses TC32, all-or-nothing relays TC94, Measuring relays and protection equipment TC95), apply the general rules of PCR and mention in the accompanying report the functional unit, the reference product characteristics, the reference lifetime and the use scenario which are applied consistently with the relevant IEC technical standards.Monitor digital & analog sensors input singal and provide Control singnal to field actuator by digial and analog output with an active power consumtion of 6W for 10 years
Functional Unit Unit	unit
Recyclability Potential In %	4

Environment Attributes Main

Take Back	No
China Rohs Regulation	X
Carbon Footprint	271.09198357521717
Ambient Air Temperature For Storage	-40-85 °C-40-85 °C
Environmental Disclosure	ENVPEP1403005EN
Operating Altitude	<= 16404.2 ft (5000 m)<= 16404.2 ft (5000 m)
Packaging Without Single Use Plastic	Yes
Relative Humidity	0-95 % without condensation
Pep Verification Date	2026-07-28
Psr Version	PSR-0005-ed3.1-EN-2023 12 08

Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Ambient Air Temperature For Operation	0-60 °C
Circularity Profile	ENVEOLI1403005EN
Eu Rohs Directive	Compliant By Exemption
Packaging Made With Recycled Cardboard	Yes
Reach Regulation	Reference contains Substances of Very High Concern above the threshold
Pep Code	ENVPEP1403005EN
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent external review

General Attributes

Product Or Component Type	analogue,discrete I/O base

Range Of Product	Modicon Momentum automation platform

ETIM

ETIM 8	EC001597
ETIM 10	EC001597

ETIM 9	EC001597

Output Attributes

Analogue Output Range	+/- 10 V 14 bits, +/- 10 V 14 bits+/- 10 V 14 bits, +/- 10 V 14 bits
Output Load	>= 2 kOhm 0...10 V analogue output, >= 2 kOhm 0...10 V analogue output, >= 2 kOhm 0...10 V analogue output>= 2 kOhm 0...10 V analogue output, >= 2 kOhm 0...10 V analogue output, >= 2 kOhm 0...10 V analogue output
Discrete Output Logic	positive
Discrete Output Voltage	10...30 V
Output Short Circuit Protection	with discrete output
Analogue Output Voltage	true

Discrete Output Current	2 A per group, 2 A per module0.25 A per point
Analogue Output Resolution	14 bits, +/- 10 V
Discrete Output Type	transistor
Output Overload Protection	with discrete output
Analogue Output Current	true

Surge Protection And Filtering Attributes

Surge Current	2.5 A 1 ms discrete output

Contractual Warranty Attributes

Warranty Period	18 months

Warranty	18 months

Input Attributes

Analogue Input Resolution	14 bits
Discrete Input Logic	positive
Discrete Input Voltage	24 V DC
Input Overvoltage Protection	45-45 V 10 s discrete input
Input Voltage Limits	3...32 V
