Mersen FSPDB4C FSPDB UL 1059 335A 1-Pole Power Distribution Block, 600V, Box Connector

MPN: FSPDB4C
UPC: 782001319656
PPN: FER-FSPDB4C

Spec sheet

Compare

Loading compare button...

In Stock

Company Stock:

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Looking to buy a large quantity?

To view product inventory

CAD$389.05/ EA

Qty:

Loading add to cart quantity...

Description

FSPDBs introduce a new level of safety and ease for installing power distribution blocks. An IP20 level of finger safe protection is achieved using the FSPDBs and thus eliminates the need for special covers or custom Plexiglas sheets to protect your panels. FSPDBs (sizes 1 to 4) simply snap onto 35mm DIN rail to provide the quickest installation. And since they are modular, you can form any number of poles desired. If multi-pole panel mounting is desired, multiple-pole assembly pins are available. FSPDBs provide a safe, convenient way of splicing cables, splitting primary power into a variety of secondary circuits or providing a fixed junction tap-off point.

Specifications

Rated voltage AC UL: 600 V

Frequency (Hz): 50/60 Hz

Ampere Rating (CU): 335 A

AC or DC: AC/DC

Short Circuit Rating (Class G): 100 kA with 60A Fuse

Short Circuit Rating (Class L): Not Tested

Short Circuit Rating (Class RK5): 100 kA with 100A Fuse

Short Circuit Rating (Class T): 100 kA with 400A Fuse

Number of Openings per Pole (Primary): 1

Connector Type (Primary): Box

Hole Diameter (Primary): 0.87 in

Torque Rating (Primary): 400-2/0 220; 1/0-#6 90; ;

Wire Range (Primary): 400 - #6

Installation Mounting: Screw Mount or DIN Rail

Width: 1.54 in

Height: 3.15 in

Rated voltage DC UL600 V

Ampere Rating (AL)335 A

ROHS CompliantYes

Short Circuit Rating (Class CC)100 kA with 30A Fuse

Short Circuit Rating (Class J)100 kA with 400A Fuse

Short Circuit Rating (Class RK1)100 kA with 200A Fuse

Short Circuit Rating (Standalone)10 kA

Number of Poles1-Pole

Number of Openings per Pole (Secondary)1

Connector Type (Secondary)Box

Hole Diameter (Secondary)0.87 in

Torque Rating (Secondary)400-2/0 220; 1/0-#6 90; ; ;

Wire Range (Secondary)400 - #6

Body/Insulating MaterialNylon

Length5.73 in

Weight1.3 lb
