Telemecanique Sensors 9007AW46 Limit switch, 9007AW, heavy duty industrial, precision, 15A at 120VAC, 1NO/1NC, push rod plunger, plug in, NEMA 4, 13

9007AW precision heavy duty limit switches are for applications that require better precision of operation. This limit switch has a push rod plunger with a micrometer adjustment. Limit switch has a one normally open and one normally closed snap action contact. Contacts have an A600 inductive rating and 15A resistive rating. They also have 0.5A at 125VDC, 0.2A at 250VDC and 0.02A at 600VDC ratings. They also have 0.5A at 125VDC, 0.2A at 250VDC and 0.02A at 600VDC ratings. Limit switch is 4.38 inches tall, 1.44 inches width and 2.53 inches deep Limit switch is NEMA 1, 2, 4, 12 and 13 rated. It is also IP65 rated. Limit switch is supplied with a 0.50 inch conduit entry with 14 NPT. Limit switch is UL Listed and CSA certified. It supports surface mounting. The 9007AW heavy duty metal industrial precision oil tight enclosed switches with unique features, micrometer adjustable and low temperature operation. The 9007 series limit switches are designed to withstand harsh industrial environments and are available in a wide range of options.
