Digital Watchdog DWC-MPH2W28TW MEGApix IVATM 2.1MP/1080p Pinhole ATM IP Camera, 2.8mm Lens, NDAA Compliant
- MPN: DWC-MPH2W28TW
- UPC: 812226034727
- PPN: DWD-DWC-MPH2W28TW
CAD
$1106.56
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Experience the cutting-edge technology of the MEGApix IVATM 2.1MP/1080p pinhole ATM IP camera, designed by Digital Watchdog for superior surveillance in various environments. This compact camera features a 2.8mm fixed lens that provides a wide field of view at 106.6 , ensuring comprehensive coverage while maintaining discreet aesthetics. With advanced capabilities such as True Wide Dynamic Range (WDR), Smart DNRTM 3D digital noise reduction, and intelligent video analytics, this camera excels in delivering high-quality images even in challenging lighting conditions.
Built for reliability, it supports Power over Ethernet (PoE) and offers dual-streaming capabilities, allowing for flexible integration with various video management systems, including DW Spectrum IPVMS. Enhanced security features such as HTTPS, IP filtering, and programmable privacy zones ensure your surveillance data remains protected. With a robust five-year warranty and compliance with industry standards, this pinhole camera is an excellent choice for those seeking a reliable and sophisticated surveillance solution.
Features
- 2.1MP/1080p 1/2.8" image sensor at real-time 30fps
- Intelligent Video Analytics (IVA)
- Extended Intelligent Video Analytics (IVA+ license required)
- Seamless integration and control of IVA rules with DW Spectrum® IPVMS
- Reduce false alarms
- Increase your recording storage with logic rules and smart recording
- 2.8mm fixed lens
- True Wide Dynamic Range (WDR)
- Triple codecs (H.265, H.264, MJPEG) with simultaneous streaming
- ATM pinhole camera
- Smart DNR™ 3D digital noise reduction
- Programmable privacy zones
- Auto gain control (AGC)
- Backlight compensation (BLC)
- Auto white balance (AWB)
- Motion detection
- Micro SD/SDHC/SDXC class 10 card slot (card not included)
- Alarm sensor input
- Relay output
- Web server built-in
- PoE class 3 and DC12V
- ONVIF conformant, profile S
- NDAA compliant
- 5 year warranty
Documentation & Downloads
Specifications
ENVIRONMENTAL
- Operating temperature
- -4°F ~ 122°F (-20°C ~ 50°C)
- Other certifications
- FCC, CE, ROHS
Operating humidity10–90% RH (non–condensing)
MECHANICAL
- Material
- Plastic
- Warranty
- 5 year warranty
Weight0.92 lbs (0.42 kg)
ELECTRICAL
- Power requirement
- DC 12V, PoE IEEE 802.3af Class 3. (Adapter not included)
OPERATIONAL
- Shutter mode
- Auto, manual, anti-flicker, slow shutter
- Slow Shutter
- 1/2, 1/3, 1/5, 1/6, 1/7.5, 1/10
- Day / night
- Day (color) only
- Wide dynamic range (WDR)
- True WDR on, off
- Backlight compensation (BLC)
- Yes
- Privacy zones
- 16 programmable privacy masks
- Memory Slot
- Micro SD/SDHC/SDXC class 10 card (card not included)
Shutter speed1/15 ~ 1/32000
Auto gain controlAuto
Smart DNR™ 3D digital noise reductionYes
Wide dynamic range (WDR) dB120dB
Mirror and flipYes
Alarm notificationsEmail, alarm output, FTP server or SD card recording
I/O
- Alarm in/out
- 1/1
LENS
- Focal length
- 2.8mm, F2.2
- Field of view (FoV)
- 106.6°
Lens typeFixed lens
NETWORK
- LAN
- RJ45 (10/100Base-T)
- Frame rate
- Up to 30fps at all resolutions
- Streaming capability
- Dual-stream at different rates and resolutions
- Protocol
- TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3 (MIB-2), ONVIF
- ONVIF conformance
- Yes
- Video management software
- DW Spectrum® IPVMS
Video compression typeH.264, MJPEG
Video bitrate100Kbps ~ 10Mbps, multi-rate for preview and recording
IPIPv4
SecurityHTTPS (TLS), IP filtering, 802.1x, Digest Authentication (ID/PW)
Web viewerOS - Windows®, Mac® OS, Linux® Browser - Internet Explorer®, Google Chrome®, Mozilla Firefox®, Safari®
- Image sensor
- 2.1MP/1080p 1/2.8" CMOS
Total pixels1945(H) X 1109(V)
