Square D QOB260H Miniature Circuit Breaker 60A 2 Pole 240VAC 10kA Bolt-On Mount
Square D QOB260H Miniature Circuit Breaker 60A 2 Pole 240VAC 10kA Bolt-On Mount
- MPN: QOB260H
- UPC: 785901335467
- PPN: SCH-QOB260H
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
CAD$240.63/ EA
Description
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 60A at 240VAC. This unit provides 10kA breaking capacity and bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
Specifications
- Current Rating
- 60 A
- Breaking Capacity
- 10 kA 120/240 V AC 50/60 Hz
- Mounting Type
- bolt-on
- Trip Mechanism
- over center, trip free toggle
- Wire Size
- AWG 8...AWG 2 copper or aluminum
- Height
- 79 mm
- Depth
- 74 mm
- Ambient Temperature Rating
- 40 6C
- Electrical Connection
- box lugs
- Mercury Free
- Yes
- Product Certifications
- UL listed, CSA
- Number of Spaces Required
- 2
- Sustainable Offer Status
- Green Premium product
Voltage120/240 V AC
Poles2
Circuit Breaker Typestandard
Trip IndicationVisiTrip visual
Tightening Torque5.6 N.m
Width38 mm
Net Weight0.322 kg
Product Typeminiature circuit-breaker
RoHS ComplianceCompliant with exemptions
Halogen ContentHalogen free product
Circuit Breaker ApplicationHACR rated
RangeQO
