Schmersal 101160849 NWSP32WS Selector Switch, 3 Position, 85 mm Width, Plastic Housing, White
- MPN: 101160849
- PPN: SCM-101160849
CAD
$177.37
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
NWSP32WS Selector Switch, 3 Position, 85 mm Width, Plastic Housing, White
Features
- for 3 position versions
- White
- Alternative to key-operated maintained selector switch
Documentation & Downloads
Specifications
Key Specifications
- Length
- 74 mm
- Height
- 30.5 mm
Width85 mm
Mechanical data - Dimensions
- Width
- 85 mm
- Length x Width x Height
- Grid dimensions: 74 mm x 85 mm
Height30.5 mm
Scope of delivery
- Note (scope of delivery, number and type)
- Padlocks not supplied.
General data - Features
- Fully insulated
- Yes
General data
- Versions
- Assembly housing
- Enclosure material
- Plastic
- Colour of the upper part of the enclosure
- Transparent
- Gross weight
- 40 g
Installation conditions (mechanical)arbitrarily
Material of the housing coverPlastic
Colour of the bottom part of the enclosureWhite
NoteFor 3 position versions
Ambient conditions
- Ambient temperature
- -25 ... +80 °C
- Restistance to shock
- 50 g
Resistance to vibrations10 - 150 Hz (0.5 mm / 5 g)
Mechanical data
- Mechanical life, minimum
- 100,000 Operations
- Mounting
- Screws | Mounted from the back. For this purpose there are 4 bore holes of 3.5 mm diameter, 12 mm deep for self-cutting screws. The grid measurement in 56 x 60 mm.
Actuating force, approx.0.2 N
Approvals - Standards
- Certificates
- BG
