Compression Lug Kit, 250A, Aluminum, Accepts 250-350 kcmil Wire
Square D

Square D NFALV2 Compression Lug Kit, 250A, Aluminum, Accepts 250-350 kcmil Wire

  • MPN: NFALV2
  • UPC: 785901484622
  • PPN: SCH-NFALV2

CAD

$368.85

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Company Stock:

0

Looking to buy a large quantity?

To view product inventory

Spec sheet

Description

NF Panelboard interiors can be used for applications such as commercial buildings, industrial buildings, stadiums, and offices. These interiors provide protection for commercial and industrial applications. NF Panelboards are versatile panelboards that feature a wide selection of circuit breakers, accessories, and ready to install kits. NF Panelboards have modular construction to accept field installable accessories and conversion kits. This compression lug kit is for the main lugs of the NF interior. These aluminum compression lugs are rated at 250A. Each compression lug will accept one 250 kcmil to 350 kcmil wire.

Documentation & Downloads

Specifications

Key Specifications

Quantity Per Set
set of 1
Provided Equipment
lug 4 || lug pad 3 || nut 3 || screw set 7
Product Or Component Typecompression lug

Complementary

[In] Rated Current
250-250 A
Awg Gauge
250...350 kcmil 1 aluminum/copper
Tightening Torque9.0-19.8 N.m 126.7-177.3 mm² 250...350 kcmil)
Materialaluminium

Offer Sustainability

China Rohs Regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Mercury Free
Yes
Eu Rohs Directive
Compliant
Reach Free Of Svhc
Yes
Rohs Exemption InformationYes
Toxic Heavy Metal FreeYes
Reach RegulationFree of Substances of Very High Concern above the threshold

Contractual warranty

Warranty
18 months
