Schneider Electric XENC1121 Harmony XAC Pendant Station Contact 240V 3A, 1 NC, Spring Return
- MPN: XENC1121
- PPN: SCH-XENC1121
CAD
$46.48
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Description
Experience reliable control with the Harmony XAC Pendant Station from Schneider Electric, designed to meet the demands of industrial applications. This robust contact block features a single normally closed (NC) contact and is engineered for a rated operational power of 240V and 3A, ensuring efficient performance in control circuits. With an impressive mechanical durability of up to 1,000,000 cycles, it operates effectively in a wide temperature range of -25°C to 70°C, making it suitable for various environments. The spring return mechanism enhances user safety and functionality, while the compact design and screw clamp terminals facilitate easy installation and connection. Whether for automation or control tasks, this pendant station is a dependable choice for enhancing operational efficiency.
Documentation & Downloads
Specifications
Key Specifications
- Mounting Of Block
- front mounting
- Contact Block Type
- single
- Contact Block Application
- single speed
- Contacts Type And Composition
- 1 NC
- Mechanical Interlocking
- without mechanical interlock
- Electrical Circuit Type
- control circuit
Range Of ProductHarmony XAC
Product Or Component Typecontact block
Component NameXENC
Contact Operationslow-break
Type Of Operatorspring return
Product CompatibilityXACB || XACM
Complementary
- Terminal Identifier
- (13-14)NO || (11-12)NC
- Maximum Resistance Across Terminals
- 25 MOhm
- Short-Circuit Protection
- 10 A fuse protection cartridge gG
- [Uimp] Rated Impulse Withstand Voltage
- 6 kV IEC 60947-1
- [Ui] Rated Insulation Voltage
- 500 V 3)IEC 60947-1
- Mechanical Durability
- 1000000 cycles
- Rated Operational Power In W
- 42 W DC-13 1000000 cycles 60 cyc/mn 120 V 0.5 inductive IEC 60947-5-1 appendix C || 45 W DC-13 1000000 cycles 60 cyc/mn 48 V 0.5 inductive IEC 60947-5-1 appendix C || 60 W DC-13 1000000 cycles 60 cyc/mn 24 V 0.5 inductive IEC 60947-5-1 appendix C
Terminals Description Iso N°1(11-12)NC
[Ithe] Conventional Enclosed Thermal Current10 A
Net Weight0.02 kg
Connections - Terminalsscrew clamp terminals, 1 x 2.5 mm² with or without cable end || screw clamp terminals, 2 x 1.5 mm² with or without cable end
Rated Operational Power In Va140 VA AC-15 1000000 cycles 60 cyc/mn 24 V 50/60 Hz 0.5 inductive || 385 VA AC-15 1000000 cycles 60 cyc/mn 48 V 50/60 Hz 0.5 inductive || 455 VA AC-15 1000000 cycles 60 cyc/mn 230 V 50/60 Hz 0.5 inductive || 525 VA AC-15 1000000 cycles 60 cyc/mn 127 V 50/60 Hz 0.5 inductive
Contact Code DesignationA300 AC-15, Ue = 240 V, Ie = 3 A IEC 60947-5-1 appendix A || Q300 DC-13, Ue = 250 V, Ie = 0.27 A IEC 60947-5-1 appendix A
Environment
- Ambient Air Temperature For Operation
- -25-70 °C
- Shock Resistance
- 100 gn IEC 60068-2-27
- Ambient Air Temperature For Storage
- -40-70 °C
StandardsIEC 60947-5-1 || CSA C22.2 No 14
Vibration Resistance15 gn 10-500 Hz)IEC 60068-2-6
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Toxic Heavy Metal Free
- Yes
- Reach Free Of Svhc
- Yes
- China Rohs Regulation
- X
Mercury FreeYes
Reach RegulationFree of Substances of Very High Concern above the threshold
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
