Harmony 9001K Pilot Light Head, 30 mm, 380...480V, Metal
Schneider Electric

Schneider Electric 9001KP5 Harmony 9001K Pilot Light Head, 30 mm, 380...480V, Metal

  • MPN: 9001KP5
  • UPC: 785901005704
  • PPN: SCH-9001KP5

CAD

$184.48

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Company Stock:

0

Looking to buy a large quantity?

To view product inventory

Spec sheet

Description

This product is part of the Harmony 9001K range, an offer of Ø 30mm metal pushbuttons, switches and pilot lights." "This pilot light transformer has round screw head with normal operating mode." "It is a light block transformer with rated supply voltage of 380V/480V AC and a frequency of 50Hz/60Hz." "It has a round screw head." "It is a NEMA 1/2/3/3R/4/6/12/13 rated product." "This transformer is fitted with chromium plated metal bezel." "It is ideal for petrochemical, metallurgy, mining, oil and gas applications. It is also suitable for automotive, water and wastewater treatment applications." "This product is certified by CE, CSA LR25490 class 3211 03 and UL listed file E42259 CCN NKCR." "It is installed into a Ø 30mm panel cutout." "A comprehensive range of illuminated pushbuttons, pilot lights, emergency stop buttons, selector switches, joystick controllers and accessories to fit your needs." "The modular range of Ø 30mm metal control and signaling provides robust and reliable solutions for a wide range of heavy industry applications."

Documentation & Downloads

Specifications

Key Specifications

Range Of Product
Harmony 9001K
Device Short Name
K
Product Or Component Typehead for pilot light

Complementary

[Us] Rated Supply Voltage
380...480 V
Light Source
incandescent bulb
Mounting Diameter
30 mm
Operating Mode
normal
Shape Of Screw Head
round
Supply Frequency
50...60 Hz
Bezel Materialmetal
Light Block Supplyvia transformer 380 V AC 50/60 Hz || via transformer 480 V AC 50/60 Hz
Light Block Supplyvia integral transformer
Cap/Operator Or Lens Colourwithout cap
Size30 mm
Bulb BaseBA 9s

Offer Sustainability

China Rohs Regulation
X
Rohs Exemption Information
Yes
Environmental Disclosure
ENVPEP121006EN
Eu Rohs Directive
Pro-active compliance (Product out of EU RoHS legal scope)
Weee
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Circularity ProfileN/A
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Reach RegulationReference contains Substances of Very High Concern above the threshold

Environment

Product Certifications
CE || CSA LR25490 class 3211 03 || UL listed file E42259 CCN NKCR
Nema Degree Of ProtectionNEMA 1/2/3/3R/4/6/12/13
