Schneider Electric ABS7SC1B Plug-In Solid State Relay 5 mm 24V DC 2A

MPN: ABS7SC1B
PPN: SCH-ABS7SC1B
UNSPSC: 39122333

$66.77

Available to Order from Manufacturer

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This product is part of the Modicon ABE7 range, an offer of connection sub-bases for Telefast pre-wired system. This is a plug-in solid state relay for output sub-bases. This is a 5mm wide output relay. This product allows AC or DC electrical current to be switched without mechanical movement. It is a solid sate relay with 24Vcc nominal voltage and 2A current. Its response time is lower or equal to 0.01ms from state 0 to 1, and lower or equal to 0.4ms from state 1 to 0. It weighs 0.010kg. It is suitable for Optimum and Universal output sub-bases. Modicon ABE7 means greater simplicity to rationalise wiring in automation system equipment. Pre-wired system enabling connection and adaptation of control signals of PLC cards equipped with HE10 connectors.

Features

Reduce the need for high-amperage wiring and switches
An average lifespan of millions of cycles with no deterioration in performance
An Ability to switch “OFF” AC loads at the point of zero load current

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Latvia

Weight	16 g

Important Information Attributes

Persona Type Ids	EU, OM, OM8
Response Time	<= 0.01 ms from state 0 to 1, <= 0.01 ms from state 0 to 1, <= 0.4 ms from state 1 to 0, <= 0.4 ms from state 1 to 0<= 0.01 ms from state 0 to 1, <= 0.01 ms from state 0 to 1, <= 0.4 ms from state 1 to 0, <= 0.4 ms from state 1 to 0
Carbon Footprint Of The End Of Life Phase C1 To C4	0 kg CO2 eq., 0.03327829523671258
Carbon Footprint Of The Manufacturing Phase A1 To A3	0.3 kg CO2 eq., 0.3273510080381165
Local Data Status	Publishable
Return Indicator	N
Weee Product Category	5
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	NOT_CONTAINING_SVHC
Rohs Eur In Scope	No
Rohs Eur Conformity Date	1840
China Rohs In Scope	Yes
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Market Segmentation	Industrial
Energy Efficiency Optimized	False
Returnability	No
Sustainable Packaging	No
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Data Source	extrapolated product
Customs Code	8536410030
Functional Unit Description	Other switchgear and controlgear solutions mentioned in the scope (e.g. fuses TC32, all-or-nothing relays TC94, Measuring relays and protection equipment TC95), apply the general rules of PCR and mention in the accompanying report the functional unit, the reference product characteristics, the reference lifetime and the use scenario which are applied consistently with the relevant IEC technical standards.To interface PLC I/O signals with field devices through a pre-wired relay interface, operating at 1.92 W during 10 years and a 100% use rate.
Functional Unit Unit	unit
Energy Consumption On Product Lifetime In Kwh	4204.8
Pep End Of Validity Date Calculated	2031-05-29

Persona Type Names	End User, Original Equipment Manufacturer, OEM - Control Panelbuilder
Carbon Footprint Of The Distribution Phase A4	0.003986115990196895, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase A5	0.004542686025477293, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase B2 B3 B4 B6	kg CO2 eq., 0
Local Publishable Date	2026-08-06
Weee Scope	In
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Free of Substances of Very High Concern above the threshold
Reach Compliance Directive	Free of Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	No
Tier Id	1
Function Option Id	STANDARD
Market Segmentation Id	INDUSTRIAL
Product Kit Identifier	N
Product Availability	Non-Stock - Not normally stocked in distribution facility
Software Version	v6.2.5-6
Total Lifecycle Carbon Footprint	0.4 kg CO2 eq.
Database Version	2024-01
Nbr. Of Units In Pkg.	1
Warranty In Months	18
Functional Unit Quantity	1
Reference Lifetime In Y	10
Recyclability Potential In %	5

Environment Attributes Main

Product Compatibility	ABE7R16T111, ABE7P16M111, ABE7P16T111
Reach Free Shvc	Yes
China Rohs Regulation	X
Mercury Free	Yes
Environmental Disclosure	ENVPEP1409004_V2
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
Pep Code	ENVPEP1409004_V2
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review

Take Back	No
Recycled Metal Content At Cr Level	0 %
Toxic Heavy Metal Free	Yes
Carbon Footprint	0.3691581052905033
Eu Rohs Directive	Compliant
Packaging Without Single Use Plastic	No
Reach Regulation	Free of Substances of Very High Concern above the threshold
Pep Verification Date	2026-05-29
Psr Version	PSR-0005-ed3-EN-2023 06 06
