Square D 8501XO40V01 NEMA Control Relay, 10A 24V AC Coil, 4 NO Contacts, 2.23 Inch Width
- MPN: 8501XO40V01
- UPC: 785901537045
- PPN: SCH-8501XO40V01
CAD
$246.74
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
The Schneider Electric 8501XO40V01 NEMA Control Relay is expertly designed for automation and control applications, offering robust performance with a 10A resistive load capacity at 600 VAC. Featuring four normally open contacts, this relay is well-suited for diverse operational needs, ensuring reliable switching in demanding environments. Powered by a 24 V AC supply at 60 Hz, it delivers consistent and dependable performance, making it an essential component for various industrial systems. With its NEMA-rated construction, this control relay provides the durability needed for effective integration in a wide range of applications.
Documentation & Downloads
Specifications
Additional
- Current Rating
- 10 A AC, 5 A DC
- Rated Short-Circuit Making Capacity
- 60 A 120 V AC inductive, 30 A 240 V AC inductive, 15 A 480 V AC inductive, 12 A 600 V AC inductive, 10 A <= 600 V AC resistive, 1.1 A 125 V DC inductive, 0.55 A 250 V DC inductive, 0.2 A 301...600 V DC inductive, 4 A 125 V DC inductive, 0.8 A 250 V DC resistive
- Control Circuit Voltage Limits
- 0.85...1.1 Uc AC 60 Hz
- Hold-In Power Consumption
- 23 VA 60 Hz
- Electrical Connection
- Screw clamp terminals
- Tightening Torque
- 1.02...1.36 N.m control circuit screw terminals
- Dimensions
- Height 3.5 in (88.90 mm), Width 2.23 in (56.64 mm), Depth 3.95 in (100.33 mm)
- Certifications
- UL listed, CSA
- Mercury Free
- Yes
Rated Breaking Capacity6 A 120 V AC inductive, 3 A 240 V AC inductive, 1.5 A 480 V AC inductive, 1.2 A 600 V AC inductive, 10 A <= 600 V AC resistive, 1.1 A 125 V DC inductive, 0.55 A 250 V DC inductive, 0.2 A 301...600 V DC inductive, 4 A 125 V DC resistive
Coil Voltage24 V AC 60 Hz
Inrush Power148 VA 60 Hz
Operating Time15 ms pick-up, 16 ms drop-out
AWG GaugeAWG 18...AWG 12 copper
Mounting TypePanel
Operating Temperature-40...160 °F (-40...71 °C)
RoHS ComplianceYes
Country of OriginMexico
