Carlo Gavazzi PMR10RIT Photoelectric Sensor, Retro-reflective - Retro-reflective, Photoelectric Sensor, range 12 m, Infrared modulated light 880nm, Power Supply 10.8-264VDC&21.6-264VAC, Relay SPDT, NO+NC, Terminals, IP67. 1/2 NPT, Time delay
Carlo Gavazzi PMR10RIT Photoelectric Sensor, Retro-reflective - Retro-reflective, Photoelectric Sensor, range 12 m, Infrared modulated light 880nm, Power Supply 10.8-264VDC&21.6-264VAC, Relay SPDT, NO+NC, Terminals, IP67. 1/2 NPT, Time delay
- MPN: PMR10RIT
- PPN: CLG-PMR10RIT
Spec sheet
Loading compare button...
Available to Order
Company Stock:
0
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To view product inventory
CAD$323.57/ EA
Description
Photoelectric Sensor, Retro-reflective - Retro-reflective, Photoelectric Sensor, range 12 m, Infrared modulated light 880nm, Power Supply 10.8-264VDC&21.6-264VAC, Relay SPDT, NO+NC, Terminals, IP67. 1/2 NPT, Time delay
Specifications
Specifications
- Predictive maintenance
- No
- Rated switching distance
- 10000
- Output current, maximum
- 3000
- Analogue output 0 V ... 10 V
- No
- Analogue output 4 mA ... 20 mA
- No
- With other analogue output
- No
- With communication interface analogue
- No
- With communication interface CANOpen
- No
- With communication interface Ethernet
- No
- With communication interface PROFIBUS
- No
- With communication interface RS-422
- No
- With communication interface SSD
- No
- Type of interface for safety communication
- Other
- Output type
- Relay contact
- Operation agent-safety class
- Safety class 0
- Width
- 25
- Length
- 81
- Material of optical surface
- Plastic
- Min. reflector distance
- 10000
- Time of reaction
- 20
- Type of safety acc. IEC 61496-1
- 1
- Rated control supply voltage Us at AC 50HZ
- Min.21.6-Max.264
- Rated Operetional voltage UB at DC
- Min.10.8-Max.264
- With monitoring function downstream switching devices
- No
- Type of light
- Infrared light
- With restart blockage
- No
- Degree of protection
- IP67
- With approval according to UL
- Yes
- Wall mounting/direct mounting
- Yes
- Housing material, specific
- Plastic
- IO-Link
- No
- Item Code 3
- ERT25 | ERT50 | ER1 | ER100 | ER390 | ER4 | ER4060 | ER420 | ER42182 | ER423 | ER460 | ER483 | ER5060 | ER5080 | ER530 | ER640 | ER665 | ER681 | ER686 | ER689 | ER692 | ER8 | ER840
- Product Main Family Group
- Photoelectric sensors
Time DelaysYes
Sensing range, maximum10000
Target includedNo
Analogue output 0 mA ... 20 mANo
Analogue output -10 V ... +10 VNo
Setting procedureManual adjustment
With communication interface AS-InterfaceNo
With communication interface DeviceNetNo
With communication interface INTERBUSNo
With communication interface RS-232No
With communication interface RS-485No
With communication interface SSINo
Connection TypeScrew connection
Output functionChange-over contact (NO/NC)
Housing styleRectangular
Height65
Sensing modeLight-/dark switching
Housing MaterialPlastic
Ambient temperatureMin.-25-Max.55
Switching frequency20
Switching voltage of OSSD at state "high"264
Rated control supply voltage Us at AC 60HZMin.21.6-Max.264
Voltage typeAC/DC
Wavelength of the sensor880
Light dot size61500
Suitable for safety functionsNo
Degree of protection (NEMA)1
Rail mounting possibleNo
ECOLAB approvedNo
Degree of protection (IP)IP67
Item Code 1MB02
Product Main FamilySensors
