Schneider Electric NSYSD10 Spacial SD Mult-purpose Control Desk 1000x1000x466 mm IP55
- MPN: NSYSD10
- PPN: SCH-NSYSD10
CAD
$2378.49
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The Spacial SD control desk from Schneider Electric is a versatile and robust solution designed to enhance operational efficiency in control environments. With its generous dimensions of 1000x1000x466 mm and an IP55 rating, this multi-purpose desk offers both ample workspace and protection against dust and water ingress. Engineered for durability and adaptability, it provides a reliable platform for managing various industrial control functions, making it an ideal choice for professionals seeking both functionality and quality in their operations.
Documentation & Downloads
Specifications
Key Specifications
| Installation Accessory Type | floor-standing |
|---|---|
| Product Name | Spacial SD |
| Enclosure Nominal Height | 1000 mm |
| Device Application | multi-purpose |
| Range | Spacial |
| Product Or Component Type | monobloc control desk |
|---|---|
| Device Composition | 1 structure || 2 lock door || 4 adjustment rail || 1 cable gland plate || 2 pneumatic stay desk lid || 2 door |
| Enclosure Nominal Depth | 466 mm |
| Enclosure Nominal Width | 1000 mm |
Complementary
| Accessibility For Operation | front |
|---|---|
| Body Type | single piece structure folded and welded |
| Material | body steel |
| Thickness | 1.5 mm |
| Door Type | plain |
| Mounting Plate Description | without mounting plate |
| Removable Parts | door by hinges || desk lid by hinges || cable gland plate by clipping screws |
|---|---|
| Type Of Gland Plate | 1 entry plate |
| Surface Finish | epoxy-polyester powder |
| Lock Type | 2 points lock, 3 mm double-bar |
| Door Opening Side | reversible 120 ° door |
| Number Of Doors | front 2 |
Environment
| Ik Degree Of Protection | IK10 IEC 62262 |
|---|---|
| Ip Degree Of Protection | IP55 IEC 60529 |
| Standards | IEC 62208 |
|---|
Contractual warranty
| Warranty | 18 months |
|---|
Offer Sustainability
| China Rohs Regulation | Product out of China RoHS scope. Substance declaration for your information |
|---|---|
| Rohs Exemption Information | Yes |
| Environmental Disclosure | ENVPEP100104EN |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Circularity Profile | N/A |
|---|---|
| Mercury Free | Yes |
| Sustainable Offer Status | Green Premium product |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
