Telemecanique Sensors XS230AANAL2 Inductive proximity sensors XS, inductive sensor XS2 M30, L60mm, PPS, Sn22mm, 12...48 VDC, cable 2 m
- MPN: XS230AANAL2
- PPN: TES-XS230AANAL2
CAD
$132.30
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
The XS range is an offer of inductive proximity sensors for the detection, without physical contact, of metal objects. The advantages of inductive detection are numerous, no physical contact with the object to be detected. Thus avoiding wear and enabling detection of fragile or freshly painted objects. This sensor is part od the food and beverage processing series. It is a cylindrical, non flush mountable sensor. Diameter 30mm, threaded M30 x 1.5. It features a plastic cylindrical boby and a 2m long cable. It has a sensing distance of 22mm. Three-wire, DC supply, 12V to 48V, NO function, NPN solid-state output .
Documentation & Downloads
Specifications
Key Specifications
- Electrical Connection
- cable
- Discrete Output Type
- NPN
- Type Of Output Signal
- discrete
- Cable Length
- 2 m
- Material
- plastic
- Wiring Technique
- 3-wire
- Series Name
- Application
- [Sn] Nominal Sensing Distance
- 22 mm
- Detector Flush Mounting Acceptance
- non flush mountable
- Sensor Design
- cylindrical M30
- Output Circuit Type
- DC
[Us] Rated Supply Voltage12...48 V DC reverse polarity protection
Discrete Output Function1 NO
Range Of ProductTelemecanique Inductive proximity sensors XS
Sensor NameXS2
Size60 mm
Ip Degree Of ProtectionIP68 double insulation conforming to IEC 60529 || IP69K conforming to DIN 40050
Body Typefixed
Sensor Typeinductive proximity sensor
Switching Capacity In Ma<= 200 mA overload and short-circuit protection
Market Segmentpharmaceutical
Device Applicationfood and beverage
Complementary
- Current Consumption
- <= 10 mA no-load
- Status Led
- output state 1 LED yellow)
- Maximum Voltage Drop
- <2 V closed)
- Marking
- CE
- Switching Frequency
- <= 500 Hz
- Sensing Range
- > 0.59...1.57 in (> 15...40 mm)
- Maximum Delay Recovery
- 1.4 ms
- Supply Voltage Limits
- 10-58 V DC
- Detection Face
- frontal
- Cable Composition
- 3 x 0.34 mm²
Maximum Delay Response0.6 ms
Operating Zone0-17.6 mm
Threaded Length51 mm
Length60 mm
Thread TypeM30 x 1.5
Differential Travel1...15% of Sr
Maximum Delay First Up10 ms
Wire Insulation MaterialPVC
Enclosure MaterialPPS
Front MaterialPPS
Environment
- Product Certifications
- CCC || CSA || UL
- Vibration Resistance
- 25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
- Ambient Air Temperature For Storage
- -40-85 °C
Ambient Air Temperature For Operation-25-85 °C
Shock Resistance50 gn 11 ms IEC 60068-2-27
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP111006EN
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Circularity Profile
- ENVEOLI1110045
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
California Proposition 65WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
