TeSys Vario 40A Control Module, IP20, 690V, 74mm Height
Schneider Electric

Schneider Electric VZ2 TeSys Vario 40A Control Module, IP20, 690V, 74mm Height

  • MPN: VZ2
  • PPN: SCH-VZ2

CAD

$41.00

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

VZ2 is an add-on main pole module for TeSys Vario switch-disconnector from Schneider Electric. Rated 40A 690V, to be used with V2 switch bodies. A maximum of 3 additional VZ2 modules can be attached to the switch body. Available worldwide, multi-standards certified (IEC, UL, CSA, CCC, EAC). Multi standards certified (IEC, UL, CSA, CCC, EAC).

Documentation & Downloads

Specifications

Key Specifications

Country of Origin
Brazil, Czechia, France
Depth35 mm

Important Information Attributes

Persona Type Ids
EU, LC, OM, OM8, PB
Market Segmentation Id
COMMERCIAL, INDUSTRIAL
Mounting Location
left, right
Certificate Agency
CSA, GL, UL, UKCA
Carbon Footprint Of The End-of-life Phase [C1 To C4]
0.1 kg CO2 eq., 0.13483783783783782
Carbon Footprint Of The Manufacturing Phase [A1 To A3]
0.3 kg CO2 eq., 0.341402027027027
Local Data Status
Publishable
Return Indicator
N
Stock Policy
2
Serviceability
No
Weee Scope
In
Scope Perimeter
At least in Europe
Reach Full Compliance Status
Reference contains Substances of Very High Concern above the threshold
Reach Compliance Directive
Reference contains Substances of Very High Concern above the threshold
Rohs Eur Status
Compliant By Exemption
Rohs Eur Full Compliance Status
Compliant By Exemption
With Recycled Cardboard
Yes
Product Contributes To Saved And Avoided Emissions
No
Tier
2
Function Option
Standard
Compatibility Code
main pole module
Device Short Name
VZ
Fire Resistance
960 °C IEC 60695-2-1
Mechanical Robustness
vibrations 10...150 Hz 1 gn) IEC 60068-2-6shocks 11 ms 30 Gn) IEC 60068-2-27
Number Of Poles
1P
Product Availability
Non-Stock - Not normally stocked in distribution facility
Protective Treatment
TC
Returnability
No
Suitability For Isolation
yes
Tightening Torque
power circuit 2.1-2.1 N.m screw clamp terminals
Weee Label
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Database Version
2022-01
Pcr Version
PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep
Independent internal review
Functional-unit Description
Turn off all or part of an installation by separating the installation or part of the installation of all electrical energy or earth, for safety reasons with a rated voltage 690V and rated current 12A ensuring isolation characterized by rated voltage 8KV. This function is provided for 20 years.
Functional-unit Unit
unit
Energy Model - Manufacturing [A1-a3]
Electricity Mix; Production mix; Low voltage; CZ
Energy Model - Use [B6]
Electricity Mix; Production mix; Low voltage; FR
Recyclability Potential In %
35
Width Nominal
16 mm
[Ithe] Conventional Enclosed Thermal Current
32 A
[Uimp] Rated Impulse Withstand Voltage
8 kV
Halogen-free Status
Halogen free product
Package Weight(Lbs)
47.000 g
Warranty (In Months)
18
Persona Type NamesEnd User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
Market SegmentationCommercial, Industrial
Network TypeAC, DC
Carbon Footprint Of The Distribution Phase [A4]0.007846013513513512, 0 kg CO2 eq.
Carbon Footprint Of The Installation Phase [A5]0.02661486486486486, 0 kg CO2 eq.
Carbon Footprint Of The Use Phase [B2 B3 B4 B6]0.5 kg CO2 eq., 0.4993700000000001
Local Publishable Date2026-06-27
Stocking FlagY
Device TypeLV equipment - LV fuse - switch
TraceabilityNo
Weee Product Category5
Eoli Availability DisplayNo need of specific recycling operations
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeYes
Rohs Eur Conformity Date1936
China Rohs In ScopeNo
Without Single Use PlasticYes
Tier Id2
Function Option IdSTANDARD
Product Kit IdentifierN
Contacts Type And Composition1 NO
Electrical Durability100000 cycles AC-2130000 cycles DC-1...5
Mechanical Durability100000 cycles
Network Frequency50/60 Hz
Performance Levelhigh performance
Product Or Component Typeadditional pole
RangeTeSys
Software Versionv5.9.4
Sustainable PackagingNo
Total Lifecycle Carbon Footprint1 kg CO2 eq.
Pep CodeENVPEP2211001EN
Pep Verification Date2025-06-18
Psr VersionPSR-0005-ed2-2016 03 29
Data Sourceextrapolated product
Functional-unit Quantity1
Reference Lifetime In Y20
Energy Model - Installation [A5]Electricity Mix; Production mix; Low voltage; FR
Energy Model - End Of Life [C1-c4]Electricity Mix; Production mix; Low voltage; FR
Height Nominal74 mm
[Ith] Conventional Free Air Thermal Current40 A
[Ue] Rated Operational Voltage690 V AC 50/60 Hz
Connections - Terminalspower circuit screw clamp terminals 6-6 mm² flexible - with cable endpower circuit screw clamp terminals 10-10 mm² solid
Nbr. Of Units In Pkg.1
Take-backNo
Customs Code8536904000

Environment Attributes Main

China Rohs Regulation
Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
Take Back
No
Recycled Metal Content At Cr Level
0 %
Carbon Footprint
1.0100707432432432
Eu Rohs Directive
Compliant By Exemption
Ip Degree Of Protection
IP20 conforming to IEC 60529
Packaging Without Single Use Plastic
Yes
Reach Regulation
Reference contains Substances of Very High Concern above the threshold
Pep Verification Date
2025-06-18
Psr Version
PSR-0005-ed2-2016 03 29
Ambient Air Temperature For Operation-20-50 °C, -20-50 °C
Halogene PerformanceHalogen free product
Mercury FreeYes
Environmental DisclosureENVPEP2211001EN
Halogen Content PerformanceHalogen free product
Packaging Made With Recycled CardboardYes
Product CompatibilityV2
Pep CodeENVPEP2211001EN
Pcr VersionPEP-PCR-ed4-2021 09 06
Type Of Verification For The PepIndependent internal review

General Attributes

Product Or Component Type
additional pole

ETIM

ETIM 8
EC000041
ETIM 9EC000041

Contractual Warranty Attributes

Warranty Period
18 months
Warranty18 months
