Schneider Electric ZBRT1 Harmony XB5R Wireless Push Button Transmitter, IP30, 25g, 100 m Range

  • MPN: ZBRT1
  • PPN: SCH-ZBRT1
  • If you can't find the product or are unsure which one you need, please use the Product Selector tool below

    • CAD

    $92.69

    / EA

    Available to Order

    Lead times may vary. For an accurate estimate please contact us.

    Available To Ship Immediately:0

    Loading dialog...

    Looking to buy a large quantity?

    To View Branch Inventory And Your Custom Pricing

    Spec sheet

    Description

    This transmitter is part of the range Harmony XB5R plastic and XB4R metal wireless and batteryless pushbuttons. It features a transmitter for wireless and batteryless pushbutton. It provides 1 radio frame sent at the push of the button. It operates with the protocol Zigbee green power 2.4 GHz in compliance with IEEE 802.15.4. It weighs 25g.

    Features

    • This innovative transmitter converts the mechanical energy generated by pushing the button into immediate electrical power, completely eliminating the need for internal batteries or hardwired control circuit loops.
    • Utilizing the low-power Zigbee Green Power protocol (IEEE 802.15.4) on the standard 2.4 GHz frequency band, this omnidirectional transceiver manages 16 independent data channels with precise O-QPSK modulation. It transmits a single secure, dedicated radio frame in less than 2 milliseconds, providing lightning-fast signal execution while coexisting harmoniously alongside local wireless data infrastructure without signal cross-talk.
    • Engineered to deliver robust data telemetry, this compact module supports a transmission range of up to 100 meters (328 feet) in an open, free-field environment, or 25 meters when integrated into standard plastic field boxes paired with centralized metal enclosures. This reliable long-range coverage gives field technicians the mobility to safely control complex machinery, automated gates, or material handling systems from a distance without physical tethering.
    • Built to survive demanding industrial operations, this heavy-duty plastic module features a mechanical durability rating of 1,000,000 continuous operation cycles requiring a strict 10 N actuation force to prevent accidental tripping. It is highly resistant to industrial vibration, withstands intense 50 gn shocks, and carries a verified 1,000 mm free-fall resistance rating to prevent unexpected downtime caused by dropped components during cabinet retrofits.
    • Designed with a standardized 22mm mounting diameter, this ultra-lightweight 25gn transmitter integrates cleanly behind Harmony XB5 plastic operator heads. This universal physical footprint ensures direct compliance with UL 508, CSA C22.2 No 14, and IEC 60947-5-1 standards, enabling simple screw-nut panel fixation under the control head without modifying your existing layout or sheet-metal cutouts.

    Documentation & Downloads

    Specifications

    Key Specifications

    Country of OriginFrance, United States

    Communications & Management Attributes

    Communication Port ProtocolZigbee green power 2.4 GHz IEEE 802.15.4

    Physical Attributes

    Cad Overall Depth43 mm
    Cad Overall Width30 mm
    Cad Overall Height41.5 mm
    Embedding Depth42 mm

    Complementary Attributes

    Maximum Sensing Distance100 m in free field25 m transmitter in a plastic box type XAL D and receiver in a metal enclosure300 m transmitter in box type XAL D, receiver in metal enclosure and use relay-antenna

    Important Information Attributes

    Persona Type IdsBM9, EU, LC, OM, OM8, PB, SC, SI, VR
    Market Segmentation IdCOMMERCIAL, INDUSTRIAL
    Radio AgreementANATEL, ARIB T66, FCC, ICASA, RSS
    Vibration Resistance+/- 10 mm (f= 2-11 Hz) conforming to IEC 60068-2-6, +/- 10 mm (f= 2-11 Hz) conforming to IEC 60068-2-6, +/- 10 mm (f= 2-11 Hz) conforming to IEC 60068-2-65 gn (f= 11-500 Hz) conforming to IEC 60068-2-6, +/- 10 mm (f= 2-11 Hz) conforming to IEC 60068-2-6, +/- 10 mm (f= 2-11 Hz) conforming to IEC 60068-2-6
    Carbon Footprint Of The Distribution Phase [A4]0.0029583, 0 kg CO2 eq.
    Carbon Footprint Of The Installation Phase [A5]0.00050028, 0 kg CO2 eq.
    Carbon Footprint Of The Use Phase [B2 B3 B4 B6]1 kg CO2 eq., 1.3996
    Local Publishable Date2026-01-12
    Stocking FlagY
    Use Carbon Footprint1.3996
    Weee Product Category5
    Eoli Availability DisplayYes
    Reach Full Compliance StatusReference contains Substances of Very High Concern above the threshold
    Reach Compliance DirectiveReference contains Substances of Very High Concern above the threshold
    Rohs Eur StatusCompliant By Exemption
    Rohs Eur Full Compliance StatusCompliant By Exemption
    China Rohs Label5
    Without Single Use PlasticYes
    Tier Id1
    Function Option IdSTANDARD
    Product Kit IdentifierN
    Antenna Typeomnidirectional
    Contact Operationsimple action push-button)
    Electrical Composition CodePW1
    Fixing Modefixing nut beneath head 2-2.4 N.m
    Max Power Consumption In W1 mW
    Mechanical Robustnessfree fall resistance 1000 mm IEC 60068-2-32
    Mounting Diameter22 mm
    Operating Force10 N C/O changing electrical state
    Product AvailabilityStock - Normally stocked in distribution facility
    Range Of ProductHarmony XB5
    ReturnabilityYes
    Sustainable PackagingYes
    Transmission Frequency2405 MHz
    Pep CodeENVPEP2009013EN
    Pep Verification Date2020-11-01
    Psr VersionPSR-0005-ed2-EN-2016 03 29
    Data Sourcereferent product
    Reference Lifetime In Y10
    Energy Model - Installation [A5]Electricity Mix; AC; <lt/> 1kV; EU-27
    Energy Model - End Of Life [C1-c4]Electricity Mix; AC; <lt/> 1kV; EU-27
    Nbr. Of Units In Pkg.1
    Silicone-freeYes
    Warranty (In Months)18
    Air Pollution (M3) Manufacturing [A1-a3]16.868
    Depletion Of Abiotic Resources - Fossil Fuels (Mj) Total Life Cycle15.916
    Depletion Of Abiotic Resources - Fossil Fuels (Mj) Operational Energy Use [B6]14.417
    Global Warming (Kg.Equivalent.Co2) Operational Energy Use [B6]1.3996
    Non-hazardous Waste Disposed Of (Kg) Operational Energy Use [B6]5.2351
    Total Use Of Non-renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Manufacturing [A1-a3]1.9619
    Total Use Of Primary Energy During The Life Cycle (Mj) Total Life Cycle30.596
    Total Use Of Primary Energy During The Life Cycle (Mj) Operational Energy Use [B6]28.354
    Total Use Of Renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Operational Energy Use [B6]2.0288
    Use Of Non-renewable Primary Energy Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Manufacturing [A1-a3]1.7409
    Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials (Mj) Total Life Cycle2.0751
    Water Pollution (M3) Total Life Cycle86.18
    Water Pollution (M3) Operational Energy Use [B6]58.726
    Customs Code8517620090
    Persona Type NamesCharge Point Operator, End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician, System Integrator, IT Channel Partner
    Market SegmentationCommercial, Industrial
    Shock Resistance25 gn 6 ms) 6000 shocks IEC 60068-2-27, 30 gn 18 ms) half sine wave acceleration IEC 60068-2-2750 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Certificate AgencyCSA, GOST, CCC, C-tick, UL, BT 2006/95/EC
    Carbon Footprint Of The End-of-life Phase [C1 To C4]0 kg CO2 eq., 0.0093641
    Carbon Footprint Of The Manufacturing Phase [A1 To A3]0.2 kg CO2 eq., 0.17132
    Local Data StatusPublishable
    Return IndicatorY
    Stock Policy1
    Weee ScopeIn
    Scope PerimeterAt least in Europe
    End Of Life Doc RefENVEOLI2009013EN
    Reach Full Compliance Status IdCONTAINS_SVHC
    Rohs Eur In ScopeNo
    Rohs Eur Conformity Date1930
    China Rohs In ScopeYes
    With Recycled CardboardYes
    Product Contributes To Saved And Avoided EmissionsNo
    Tier1
    Function OptionStandard
    Antenna Gain0 dBi
    Bezel Materialplastic
    Device Short NameXB5R
    Electromagnetic Compatibilityelectrostatic discharge immunity test - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2electrostatic discharge immunity test - test level: 4 kV (on contact (on metal parts)) conforming to IEC 61000-4-2susceptibility to electromagnetic fields - test level: 20 V/m (80...3000 MHz) conforming to IEC 61000-4-3susceptibility to electromagnetic fields - test level: 6 V/m (3000...6000 MHz, distance = 20 m) conforming to IEC 61000-4-3
    Level Or Class5M00G7W
    Mechanical Durability1000000 cycles
    Modulation TechniqueO-QPSK
    Number Of Channels16
    Operating Travel4.3 mm total travel)
    Product Or Component Typewireless and batteryless transmitter
    Response Time< 2 ms< 2 ms
    Software VersionEIME v5.8.1
    Total Lifecycle Carbon Footprint2 kg CO2 eq.
    Weee LabelThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Database Version2016-11
    Pcr VersionPCR-ed3-EN-2015 04 02
    Type Of Verification For The PepIndependent internal review
    Functional-unit DescriptionThe ZBRT1 is a wireless switch block which can be mounted with an actuation head. When the head is actuated through the action of an operator the product will generate electricity in order to send a radio signal to a radio reciever for 10 years.
    Energy Model - Manufacturing [A1-a3]Energy model used: France
    Energy Model - Use [B6]Electricity Mix; AC; &lt;lt/&gt; 1kV; EU-27
    Carbon Footprint (Kg Co2 Eq Total Life Cycle)1.5837
    Package Weight(Lbs)18 g
    Take-backNo
    Air Pollution (M3) Total Life Cycle77.218
    Air Pollution (M3) Operational Energy Use [B6]60.023
    Depletion Of Abiotic Resources - Fossil Fuels (Mj) Manufacturing [A1-a3]1.4312
    Global Warming (Kg.Equivalent.Co2) Total Life Cycle1.5837
    Non-hazardous Waste Disposed Of (Kg) Total Life Cycle5.2914
    Total Use Of Non-renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Total Life Cycle28.359
    Total Use Of Non-renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Operational Energy Use [B6]26.325
    Total Use Of Primary Energy During The Life Cycle (Mj) Manufacturing [A1-a3]2.1702
    Total Use Of Renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Total Life Cycle2.2373
    Use Of Non-renewable Primary Energy Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Total Life Cycle28.138
    Use Of Non-renewable Primary Energy Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6]26.325
    Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6]2.0288
    Water Pollution (M3) Manufacturing [A1-a3]26.5
    Water Pollution (M3) End Of Life [C1-c4]0.3921

    Environment Attributes Main

    Ambient Air Temperature For Operation-40-70 °C, -40-70 °C
    Directives1999/5/EC - R&TTE directive, 2004/108/EC - electromagnetic compatibility
    Recycled Metal Content At Cr Level0 %
    Silicon FreeYes
    Circularity ProfileENVEOLI2009013EN
    Eu Rohs DirectiveCompliant By Exemption
    Packaging Made With Recycled CardboardYes
    Reach RegulationReference contains Substances of Very High Concern above the threshold
    Pep CodeENVPEP2009013EN
    Pcr VersionPCR-ed3-EN-2015 04 02
    Type Of Verification For The PepIndependent internal review
    Ambient Air Temperature For Storage-40-70 °C, -40-70 °C
    Take BackNo
    China Rohs RegulationX
    Carbon Footprint1.5837
    Environmental DisclosureENVPEP2009013EN
    Ip Degree Of ProtectionIP30 IEC 60529 back face)
    Packaging Without Single Use PlasticYes
    Relative Humidity95-95 % -40-70 °C without condensation
    Pep Verification Date2020-11-01
    Psr VersionPSR-0005-ed2-EN-2016 03 29

    General Attributes

    Product Or Component Typewireless and batteryless transmitter
    Range Of ProductHarmony XB5

    ETIM

    ETIM 8EC001358
    ETIM 9EC001358

    Contractual Warranty Attributes

    Warranty Period18 months
    Warranty18 months
