Tripp Lite U236-MMF-LC USB 2.0 Ethernet NIC Adapter, 10/100 Mbps, Multimode Fiber, LC Connector
- MPN: U236-MMF-LC
- UPC: 037332248473
- PPN: TRP-U236-MMF-LC
CAD
$208.75
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
USB 2.0 Ethernet NIC Adapter, 10/100 Mbps, Multimode Fiber, LC Connector
Features
- Connects you to a wired Ethernet network when Wi-Fi is weak or unavailable
- Provides 10/100 Mbps throughput up to 2 km (1.2 mi.) via multimode fiber cabling
- Supports USB 2.0 speeds up to 480 Mbps to ensure efficient data transfers
- Hot-swappable interface lets you install and uninstall without shutting down computer
- USB 2.0 Ethernet adapter powered via USB, so no external power supply is required
- 3-year limited warranty
- Connects Your USB Device to a Wired Ethernet Network without an Internet Card Installed
- Hot-Swappable for Installation Without Network Interruption
- Delivers Full Ethernet Performance with Audio and Video Streaming
Documentation & Downloads
Specifications
Features & Specifications
| USB Specification | USB 2.0 (up to 480 Mbps) |
|---|---|
| Remote Wakeup Support | Yes |
| Wavelength | 1310nm |
| Transmission Distance | 2km |
| Driver Required | Yes |
|---|---|
| Technology | USB; USB 2.0 (High Speed) |
| Optical Port | LC |
| Mode Type | Multimode |
Certifications
| Certifications | Tested to CE, FCC, RoHS, REACH |
|---|
Connections
| Side A - Connector 1 | USB A (MALE) |
|---|---|
| Connector Plating | Nickel |
| Side B - Connector 1 | LC DUPLEX (FEMALE); RJ45 (FEMALE) |
|---|
Physical
| Cable Jacket Rating | VW-1 |
|---|---|
| Material of Construction | ABS, PVC |
| Unit Packaging Type | Box |
| Color | White |
|---|---|
| Unit Dimensions (hwd / in.) | 0.71 x 2.2 x 1.61 |
| Unit Weight (lbs.) | 0.12 |
User Interface, Alerts & Controls
| LED Indicators | Blue (Power/Data) |
|---|
Input
| Built-In Cable Length (m) | 0.155 |
|---|---|
| Bus Powered | Yes |
| Built-In Cable Length (in.) | 6.1 |
|---|
Communications
| Network Speed | 10/100 Mbps |
|---|
Environmental
| Operating Temperature Range | 32 to 131°F (0 to 55°C) |
|---|---|
| Relative Humidity | 5% to 90 % RH, Non-Condensing |
| Storage Temperature Range | 32 to 140°F (0 to 60°C) |
|---|
Overview
| UPC Code | 037332248473 |
|---|
Warranty
| Product Warranty Period (Worldwide) | 3-year limited warranty |
|---|
