Mersen USM1I-AC120 UltraSafe Midget Fuseholder, 0-30 A, IP20, 1-4 Poles, DIN-Rail Mounting
- MPN: USM1I-AC120
- UPC: 782001831608
- PPN: FER-USM1I-AC120
CAD
$88.88
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Mersen UltraSafe modular fuseholders introduce a new level of safety for class CC and midget fuses up to 30 amperes. UltraSafe fuseholders qualify as "finger safe" under IEC and DIN standards to an IP20 grade of protection, including fuse changing (with the flick of a finger). UltraSafe fuseholders are available in 1, 2, 3 or 4 poles, with or without visual blown-fuse indicators in each pole. Multiple poles can be assembled in the field by ordering and installing pin-tie handles. UltraSafe fuseholders save up to 15% mounting space and any combination can be snapped onto 35mm DIN rail for extra savings in panel building time. Choose class CC fuses for Type "2" no-damage protection, one of the safest protection packages in the industry. The UltraSafe body material is tough and durable polyamide, with exceptional insulating properties.
Features
- DIN-rail mounting
- IP20 Finger-Safe
- Compact footprint
- Optional visual blown fuse indication
- Quick, tool-free, easy fuse change outs
Specifications
Product Details
| UL Certification | E52283 IZLT2.E52283 |
|---|---|
| Number of Poles | 1 1-4 |
| Materials Contact | Tin-plated Copper |
| CE conformity | Yes |
| Mounting | DIN-rail |
| Connection Terminal Type | Pressure Plate |
| Standards | UL Recognized Component to standard 4248-14, File E52283 CSA Certified C22.2, Class 6225, File 32169 IEC Compliant to 60269-2-1, 60947-3 |
| DC Voltage Range | 1000 VDC |
| Lead Free | Yes |
| Class | Midget |
| Body Material | Polyamide |
|---|---|
| Applications | All circuits up to 600 volts for motors, control circuits, transformers, etc. DC circuits up to 1000VDC |
| Enclosure | IP20 |
| AC Voltage Range | 800 VAC |
| Wiring Range | #6 to #14 Solid or Stranded Solid or Stranded #6 to #14 Single Conductor, #6 to #10 Dual Conductor |
| SCCR | 200AC, 100DC kA 200kA AC, 100kA DC kA |
| Ampere Range | 0-30 A |
| ROHS Compliant | Yes |
| CSA Certification | 6225-01 3211-37 |
