ILSCO NBAE-0204-1 Aluminum Neutral Bar, Dual Rated, Large Conductor Range 1/0-14, Small Range 6-14, 2 Large Ports, 4 Small Ports, 1 Hole, #10 Bolt, UL, CSA
- MPN: NBAE-0204-1
- UPC: 783669005783
- PPN: ILC-NBAE-0204-1
CAD
$14.67
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Aluminum Neutral Bar, Dual Rated, Large Conductor Range 1/0-14, Small Range 6-14, 2 Large Ports, 4 Small Ports, 1 Hole, #10 Bolt, UL, CSA
Documentation & Downloads
Specifications
Key Specifications
- Height
- 0.729 in | 18.5166 mm
- Weight
- 0.06 lbs
Length2.265 in | 57.531 mm
Width0.375 in | 9.525 mm
Voltage
- Voltage Rating
- 35 kV
Dimensions
- Dimension G (IN)
- 1.132
- Drive Type Main
- Slotted
- Height (mm)
- 18.5166
- Mounting Bolt/Stud Size (mm)
- 254
- Mounting Hole Diameter (mm)
- 5.1562
- Weight BX (LB)
- 1.295
- Width (mm)
- 9.525
Dimension G (mm)28.7528
Height BX (IN)1.9
Length (mm)57.531
Mounting Hole Diameter (IN)0.203
Mounting Hole Position (IN)4
Width BX (IN)4
Testing Standards
- CSA File Number
- LR-29601
- Prop65 Compliance
- This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
- UL File Number
- E6207
CSA StandardC22.2 No. 65-03
UL / CULUS SpecificationUL 467 Listed, UL 486A/B Recognized
Additional Class Attributes
- Connection
- Mechanical
- Number of Conductors
- 1
- Number of Poles
- 1
Mounting Hole TypeThru
Number of Mounting Holes1
Number of Ports Tap4
Material and Finish
- Conductor Material
- Copper, Aluminum
- Material
- Aluminum
- Wire Binding Hardware Material
- Steel
Connector FinishTin
Wire Binding Hardware FinishZinc Clear Trivalent Chromate
Conductor Ranges
- Conductor Range AL Solid (Secondary, tap, load)
- 10 Sol - 14 Sol
- Conductor Range AL Stranded (Secondary, tap, load)
- 6 Str - 14 Str
- Conductor Range CU Solid (Secondary, tap, load)
- 10 Sol - 14 Sol
- Conductor Range CU Stranded (Secondary, tap, load)
- 6 Str - 14 Str
Conductor Range AL Stranded (Primary, run, main, line)1/0 Str - 14 Str
Conductor Range CU Solid (Primary, run, main, line)10 Sol - 14 Sol
Conductor Range CU Stranded (Primary, run, main, line)1/0 Str - 14 Str
Conductor Range AL Solid (Primary, run, main, line)10 Sol - 14 Sol
Additional Technical Specifications
- Conductor Type
- Stranded, Solid
General
- Bag Quantity
- 1
- Dual Rated
- Yes
- UPC Code
- 78366900578
Carton Quantity DescriptionSTD PACK QTY 20
NEMA CodeS-588-3
Bolt and Screw Sizes
- Mounting Bolt/Stud Size
- #10
- Wire Binding Screw Size
- 5/16
Number of Wire Binding Screws per Port1
Wire Binding Torque10 - 14 AWG = 35, 8 AWG = 40, 8 - 6 AWG = 25, 1/0 - 2 AWG = 50, 10 - 14 AWG = 15, 4 - 6 AWG = 45
Color
- Color
- Silver
