Schneider Electric LA1KN403 TeSys K Auxiliary Contact Block 4NO 10A 690V AC Front Mounting
Schneider Electric LA1KN403 TeSys K Auxiliary Contact Block 4NO 10A 690V AC Front Mounting
- MPN: LA1KN403
- PPN: SCH-LA1KN403
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
CAD$32.78/ EA
Description
TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K). It provides 4NO contacts rated up to 10A 690V AC, connection by spring terminals. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).
Specifications
Complementary
- Permissible Short-Time Rating
- 80 A 1 s || 60 A 500 ms || 110 A 100 ms
- Height
- 30 mm
- Insulation Resistance
- > 10 MOhm
- Associated Fuse Rating
- 10 A gG at <= 690 V conforming to IEC 60947
- Connections - Terminals
- spring terminals 1 0.75-1.5 mm²flexible without cable end || spring terminals 1 0.75-1.5 mm²rigid
- Width
- 38 mm
Minimum Switching Current5 mA
Non Overlap Distance0.5 mm
Irms Rated Making Capacity110 A at <= 690 V AC conforming to IEC 60947
Net Weight0.045 kg
Minimum Switching Voltage17 V
Depth35 mm
Specifications
- Product Certifications
- CB Scheme || CCC || UL || CSA || CE || UKCA
- Standards
- EN/IEC 60947-5-1 || UL 60947-5-1 || CSA C22.2 No 60947-5-1 || GB/T 14048.5 || JIS C8201-5-1
- Range Compatibility
- TeSys K LC1K || TeSys K CA2K || TeSys K CA3K
- Product Name
- TeSys K
- Mounting Location
- front
- [Ui] Rated Insulation Voltage
- 690 V IEC 60947-5-1 || 600 V UL 60947-5-1 || 600 V CSA C22.2 No 60947-5-1
- Device Short Name
- LA1
[Ith] Conventional Free Air Thermal Current10 A (at 50 °C)
[Ue] Rated Operational Voltage690 V AC 25...400 Hz
Product Or Component Typeauxiliary contact block
RangeTeSys
Pole Contact Composition4 NO
Auxiliary Contacts Operationinstantaneous
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP2106022
- Toxic Heavy Metal Free
- Yes
- Reach Free Of Svhc
- Yes
- China Rohs Regulation
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Eu Rohs Directive
- Compliant
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Reach RegulationFree of Substances of Very High Concern above the threshold
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Circularity ProfileN/A
Environment
- Ambient Air Temperature For Operation
- -25-50 °C
- Ambient Air Temperature For Storage
- -50-80 °C
- Protective Treatment
- TC IEC 60068
Ip Degree Of ProtectionIP20 IEC 60529
Environmental Characteristicnormal environment
Operating Altitude2000 m
