Balluff BCS D22T402-PSM60C-EP02 Capacitive Sensor 22 x 16 mm, IP64, 12-30 VDC
- MPN: BCS D22T402-PSM60C-EP02
- PPN: BAL-BCS00HK
CAD
$413.54
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Capacitive sensors for object detection feature a straight-line electrical field. They detect both solid bodies, such as wafers, PCBs, cartons, paper stacks, bottles, plastic blocks and plates, and liquids through container walls or glass or plastic tubes (thickness max. 4 mm).
Documentation & Downloads
Specifications
Additional
| Operating Voltage | 12-30 VDC |
|---|---|
| Range | 5.4-6.6 mm |
| Voltage Drop Max | 1.2 V |
| Rated Insulation Voltage | 75 V DC |
| Hysteresis Max | 15 % of Sr |
| Temperature Drift Max | 10 % of Sr |
| Ambient Temperature | -30 to 70 C |
| Connection | Cable, 2.00 m, PUR |
| Material Sensing Surface | PTFE |
| Series | D22 |
| Conductor Cross-Section | 0.14 mm2 |
| Polarity Reversal Protection | Yes |
| Material Jacket | PUR |
| Switching Frequency | 100 Hz |
|---|---|
| Switching Output | PNP Normally open (NO) |
| Rated Operating Current | 300 mA |
| Switching Output | PNP Normally open (NO) |
| Repeat Accuracy Max | 2 % of Sr |
| IP Rating | IP64 |
| Dimension | 22 x 16 mm |
| Housing Material | Stainless steel (1.4301) |
| Installation | Flush mounting |
| Approval/Conformity | CE, WEEE |
| Number of Conductors | 3 |
| Short-Circuit Protection | Yes |
