Square D 8502SGO2V06 NEMA Size 5 Non-Reversing Contactor, 270A, 200HP, 3 Phase, 480VAC
- MPN: 8502SGO2V06
- UPC: 785901851110
- PPN: SCH-8502SGO2V06
- UNSPSC: 39121529
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Type S non-reversing magnetic contactors are used to switch heating loads, capacitors, transformers, and electric motors where overload protection is provided separately. Type S contactors have ratings up to 810 amperes. This 3 pole NEMA Size 5 non-reversing contactor has a 270 ampere rating. Three phase NEMA Size 5 contactors have 75 HP at 200, 100 HP at 230 VAC and 200 HP at 460 and 575 VAC ratings. This NEMA contactor has a 100 kA maximum SCCR rating per UL508A when protected by an appropriate circuit breaker or fuse. These contactors are available with replaceable coils in a wide variety of voltages. This contactor has a 440/480 VAC 50/60 Hz coil that is wired for common control. This NEMA contactor is an open device without an enclosure. This contactor is 12.31 inches tall, 8.67 inches wide and 8.75 inches deep. A wide variety of accessories are available for Type S contactors. Type S NEMA contactors are UL listed and CSA certified.
Features
- This 3 pole NEMA Size 5 non-reversing contactor has a 270 ampere rating and 480 VAC coil
- Switch heating loads, capacitors, transformers, and electric motors where overload protection is separately provided
- Robust design and reliable build for long mechanical life and electrical endurance
- Serviceable by replacing contacts and coils
- This product is TAA compliant.
