Schneider Electric LAD4TGDL contactor bi-directional limiting diode
Schneider Electric LAD4TGDL contactor bi-directional limiting diode
- MPN: LAD4TGDL
- PPN: SCH-LAD4TGDL
Spec sheet
Loading compare button...
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To view product inventory
CAD$53.97/ EA
Description
TeSys D suppressor module, for LC1D09-D38, LC1DT20-DT40 contactors and CAD control relays. To be used with 73-125V DC control circuit voltage, it provides a bidirectional peak limiting diodes protection limiting the transient voltage to 2 Uc max. Clip-on side mounting, overall size of the contactor is unchanged. Green Premium compliant (RoHS/REACh).
Specifications
Environment
- Product Certifications
- UL || CSA
- Standards
- IEC 60947-5-1 || EN 60947-5-1 || CSA C22.2 No 60947-5-1 || UL 60947-5-1 || GB/T 14048.5
- Ambient Air Temperature For Storage
- -40-80 °C
Ambient Air Temperature For Operation-25-55 °C
Ip Degree Of ProtectionIP2XIEC 60529
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP111253EN
- Toxic Heavy Metal Free
- Yes
- Reach Free Of Svhc
- Yes
- China Rohs Regulation
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Eu Rohs Directive
- Compliant
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Reach RegulationFree of Substances of Very High Concern above the threshold
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Circularity ProfileN/A
Complementary
- [Uc] Control Circuit Voltage
- 125 V DC
- Mounting Location
- side
- Mounting Mode
- by clips
Net Weight0.012 kg
Maximum Peak Voltage2 Uc
Suppressor Technologybidirectional peak limiting diode
Specifications
- Product Or Component Type
- suppressor module
- Product Compatibility
- 3P LC1D09...D38 || 4P LC1DT20...DT40 || 4P LC1D098...D258 || CAD32, CAD50
RangeTeSys
Device Short NameLAD4
