Bussmann LP-CC-7 Current-limiting Time-delay Fuse, 7A, 600 Vac, 150 Vdc, Class CC, Ferrule End
- MPN: LP-CC-7
- UPC: 051712180528
- PPN: BUS-LP-CC-7
CAD
$17.20
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Current-limiting Time-delay Fuse, 7A, 600 Vac, 150 Vdc, Class CC, Ferrule End
Features
- Engineered with a built-in 12-second time-delay at 200% overcurrent, this dual-element fuse tolerates temporary inrush currents without breaking the circuit. This essential delay eliminates expensive nuisance tripping while powering small fractional-horsepower motors, control transformers, and inductive loads, keeping your automation systems continuously online.
- Operating as a highly accurate current-limiting device, the LP-CC-7 responds instantly to catastrophic faults by physically restricting destructive thermal and magnetic energy before it can damage downstream components. This superior response speed allows panel builders to achieve code-compliant "No Damage" Type 2 coordination for NEMA and IEC motor controllers, saving high-value hardware from total destruction.
- Boasting an exceptional interrupting rating of 200,000 Amps at 600V AC (and 20,000 Amps at 150V DC), this branch-circuit fuse easily complies with stringent NEC® Section 110.9 safety mandates. It provides maximum safety for industrial control panels connected to high-capacity main distribution grids, ensuring fault currents are isolated cleanly without explosive housing failures
- Designed with a standardized 13/32" x 1-1/2" (10 times 38 mm) profile featuring a specialized rejection tip, this fuse guarantees it will only seat into proper Class CC holders. This mechanical fail-safe prevents field technicians from accidentally replacing it with lesser-rated supplementary fuses, preserving the safety integrity of the branch circuit and preventing local tracking hazards.
- Because the Low-Peak™ series combines fast short-circuit response with a reliable time-delay, it handles applications that traditionally required separate fast-acting and time-delay fuses. Upgrading to this all-purpose model can trim your active fuse inventory by up to 33%, streamlining warehousing costs and simplifying routine maintenance for facility electricians.
Documentation & Downloads
Specifications
Additional
- Amperage
- 7A
- Interrupting Rating
- 200 kAIC at 600 Vac, 20 kAIC at 150 Vdc
- Fuse Type
- Current-limiting, Time-delay
- Diameter
- 0.40625 in
- Width
- 0.41 in
- Fuse Indicator
- Non-indicating
- Compliance
- UL Listed, CSA Certified, CE Marked, RoHS Compliant
- Number Of Elements
- Dual
Voltage600 Vac, 150 Vdc
Fuse ClassClass CC
Response Time12 seconds minimum at 200% rated current
Length1.5 in
Connection TypeFerrule end X ferrule end
MaterialMelamine tube
Product Weight0.15 lb
